1. Bubuka
Thank you for choosing the Moonka 10.1-inch Wi-Fi Digital Photo Frame. This device allows you to easily share and display your cherished photos and videos with family and friends from anywhere in the world. Featuring a vibrant 10.1-inch IPS touch screen, Wi-Fi connectivity, and 32GB of internal storage, this frame offers a convenient way to relive your memories. This manual will guide you through the setup, operation, and maintenance of your new digital photo frame.
2. Émbaran Kasalametan penting
Please read all safety instructions carefully before using the product. Failure to follow these instructions may result in electric shock, fire, or damage to the device.
- Sumber Daya: Anggo ngan ukur adaptor daya anu disayogikeun. Nganggo adaptor anu teu cocog tiasa ngaruksak alat sareng ngabatalkeun garansi anjeun.
- Cai sareng Uap: Do not expose the device to water, rain, or excessive moisture. Keep it away from sinks, bathtubs, and other wet areas.
- Panas: Jauhkeun alat ieu tina sumber panas sapertos radiator, pancatat panas, kompor, atanapi alat-alat penghasil panas anu sanésna.
- Ventilasi: Pastikeun ventilasi anu leres. Ulah meungpeuk sagala bukaan ventilasi.
- beberesih: Cabut colokan alat sateuacan dibersihkeun. Anggo lawon anu lemes sareng garing. Entong nganggo pembersih cair atanapi pembersih aerosol.
- Palayanan: Entong nyobian ngalayanan produk ieu nyalira. Rujuk sadayana ngalayanan ka tanaga jasa anu mumpuni.
- panempatan: Place the frame on a stable, flat surface to prevent it from falling.
3. Eusi Paket
Pastikeun yén sadaya item kalebet dina pakét anjeun:
- Moonka 10.1-inch Wi-Fi Digital Photo Frame
- Adaptor kakuatan
- Nangtung Leungit
- Manual pamaké
Figure 3.1: Digital Photo Frame and Accessories
4. Produk Langkungview
4.1 Hareup View
Gambar 4.1: Hareupeun View of the Digital Photo Frame
The front of the frame features a 10.1-inch IPS touch screen display. The screen provides a wide viewing angle and clear image quality.
4.2 Tukangeun View jeung Palabuhan
Gambar 4.2: Tukangeun View sareng Tata Letak Pelabuhan
- Daya ON/OFF: Tombol pikeun ngahurungkeun atanapi mareuman alat.
- ResET: Small hole for resetting the device (use a pin).
- Mini-USB: For connecting to a computer or other USB devices.
- Slot Kartu SD Mikro: Insert a Micro SD card for additional storage.
- Input Daya DC: Sambungkeun adaptor kakuatan di dieu.
- Tembok Gunung Hole: Pikeun masang pigura dina témbok.
- kurung: Detachable stand for tabletop placement.
5. Setélan
5.1 Step 1: Power On
- Connect the power adapter to the DC Power Input port on the back of the frame.
- Colokkeun adaptor kakuatan kana stop kontak témbok.
- Press the Power ON/OFF button to turn on the frame.
5.2 Step 2: Initial Configuration
Upon first power-on, the frame will guide you through initial settings:
- Pilih basa anu anjeun pikaresep.
- Setel zona waktos.
- Connect to your Wi-Fi network by selecting it from the list and entering the password. The frame supports 2.5GHz Wi-Fi.
5.3 Step 3: Download the "SSA WiFi Frame" App
To easily upload and manage photos and videos, download the free "SSA WiFi Frame" app on your smartphone or tablet.
Figure 5.1: SSA WiFi Frame App Download
- Scan the QR code displayed on the frame or in the manual, or search for "SSA WiFi Frame" in your device's app store (Google Play for Android, App Store for iOS).
- Pasang aplikasi sareng ngadamel akun.
- Follow the in-app instructions to pair your smartphone with the digital photo frame using the unique device ID provided on the frame.
6. Parentah Operasi
6.1 Unggah Poto sareng Pidéo
6.1.1 Via "SSA WiFi Frame" App
The app allows for real-time sharing of photos and short videos (up to 15 seconds) directly to your frame.
- Open the "SSA WiFi Frame" app on your smartphone.
- Select the photos or videos you wish to upload.
- Tap the upload button to send them to your connected digital photo frame.
- Photos and videos will appear on the frame almost instantly, allowing family and friends to share moments regardless of distance.
6.1.2 Via Micro SD Card or USB Drive
You can also transfer media files directly using a Micro SD card or a USB drive.
- Insert a Micro SD card into the Micro SD Card Slot or a USB drive into the Mini USB port on the back of the frame.
- Navigate to the 'Files' or 'Gallery' section on the frame's touch screen.
- Select the external storage device and choose the files you want to copy to the frame's internal memory.
6.2 Viewing Poto sareng Pidéo
6.2.1 Slideshow Mode
The frame automatically starts a slideshow of all uploaded photos and videos. You can customize slideshow settings such as transition effects and display time per image in the settings menu.
6.2.2 Manual Browsing
Tap the screen to pause the slideshow and browse through your media manually. Swipe left or right to navigate between photos and videos. Tap on a video to play it.
6.3 Nyaluyukeun Setélan
Access the settings menu by tapping the screen and selecting the 'Settings' icon. Here you can customize various aspects of your frame:
- tampilan: Adjust brightness, contrast, and screen orientation (the frame also supports automatic rotation).
- Modeu Bobo: Set schedules for the frame to automatically turn on/off.
- Sénsor gerak: Enable or disable the human motion sensor. When enabled, the frame will automatically turn on when motion is detected and turn off after a period of inactivity.
- Tanggal & Waktos: Manually set or synchronize date and time via Wi-Fi.
- Volume: Adjust the volume for video playback.
Figure 6.1: Motion Sensor in Action
6.4 Fitur tambahan
The Moonka digital photo frame offers several convenient features:
- Kalénder: View tanggal sareng bulan ayeuna.
- Jam: Témbongkeun waktu ayeuna.
- Cuaca: Get real-time weather updates for your selected location (requires Wi-Fi connection).
7. Pangropéa
- Ngabersihan layar: Ngusap layar nganggo kaén anu lembut sareng teu aya serat. Pikeun smudges nekad, rada dampen lawon kalayan cai atanapi solusi beberesih layar. Hindarkeun bahan kimia anu kasar.
- Perawatan Umum: Keep the frame in a dry environment. Avoid extreme temperatures and direct sunlight.
8. Cara ngungkulan
| Masalah | Mungkin Cukang lantaranana | Solusi |
|---|---|---|
| Pigura teu hurung. | No power, faulty adapter. | Check power connection. Ensure adapter is securely plugged in. Try a different outlet. |
| Teu bisa nyambung ka Wi-Fi. | Incorrect password, out of range, 5GHz network. | Verify Wi-Fi password. Move frame closer to router. Ensure your network is 2.5GHz. |
| Poto/pidéo teu némbongan. | App not connected, incorrect file format, storage full. | Check app connection status. Ensure files are in supported formats (JPEG, MP4). Check available storage. |
| Layar teu ngaréspon. | glitch software samentara. | Restart the frame. If issue persists, use the RESET button. |
9. Spésifikasi
| Fitur | Rincian |
|---|---|
| merek | moonka |
| Nomer modél | ZN-DP1002 |
| Ukuran layar | 10.1 inci |
| Resolusi | 1280x800 |
| Tipe tampilan | Panel Toél IPS |
| Mémori internal | 32GB |
| Panyimpenan éksternal | Supports Micro SD card (up to 32GB, sold separately) |
| Konektipitas | Wi-Fi (2.5GHz) |
| Dirojong File Formulir | JPEG, JPG (photos); MPEG-1, MPEG-2, MPEG-4, H.263 (videos) |
| Dimensi produk | Approximately 4 x 3 x 2.51 cm (frame thickness) |
| Beurat produk | Kira-kira 930 g |
10. Garansi jeung Rojongan
Your Moonka Digital Photo Frame comes with a 1-year quality guarantee from the date of purchase. If you encounter any issues or have questions regarding your product, please contact our customer support team. We offer 24-hour Japanese customer support.
Inpormasi kontak:
- Please refer to your Amazon order history: Go to "Account Service" > "Order History" > "Seller" > "Ask a Question" to send us an email.
- Our team will respond promptly within 24 hours.
We are committed to providing high-quality products and services to ensure your satisfaction.
