PEPE Mobility Folding Crutch User Manual

1. Bubuka

Thank you for choosing the PEPE Mobility Folding Crutch. This crutch is designed to provide stable and comfortable support for adults requiring assistance with mobility. Its lightweight aluminum construction and adjustable features make it suitable for various users and situations. Please read this manual carefully before using the crutch to ensure proper assembly, adjustment, and safe operation.

This crutch is intended for individuals needing extra support and balance during convalescence or injury rehabilitation. It is designed for single-person use and supports a maximum weight of 220 lbs (100 kg).

2. Émbaran Kasalametan

• Batesan Beurat: Ulah ngaleuwihan beurat pangguna maksimum 220 lbs (100 kg).
• Inspeksi rutin: Before each use, inspect the crutch for any signs of damage, loose parts, or excessive wear, especially on the crutch tip and adjustment pins.
• Penyesuaian anu leres: Ensure all adjustment mechanisms are securely locked in place before use. Incorrect height adjustment can lead to instability and falls.
• Kasadaran permukaan: Use caution on uneven, wet, or slippery surfaces. The crutch tip provides grip, but vigilance is always required.
• Pituduh profésional: Consult with a healthcare professional or physical therapist for proper gait training and usage techniques specific to your condition.

3. Unpacking jeung Majelis

The PEPE Mobility Folding Crutch features an easy and quick folding system. Follow these steps to prepare your crutch for use:

1. Carefully remove the crutch from its packaging.
2. Unfold the crutch by extending the two main sections until they click securely into place. The internal elastic cord guides the sections together.
3. Ensure the connection point is firm and there is no wobble.

Image 3.1: The PEPE Mobility Folding Crutch, shown both folded for transport and fully extended for use.

4. adjustment jangkungna

The crutch features 7 height settings to ensure a proper fit for users between approximately 5'4" and 6'3" (depending on individual arm and leg length). Correct height adjustment is crucial for comfort and safety.

1. Locate the adjustment pin on the lower shaft of the crutch.
2. Press the adjustment pin inward and slide the lower shaft up or down to the desired height.
3. Release the pin, ensuring it fully engages in one of the adjustment holes. You should hear a click and feel the shaft lock into place.
4. To verify the correct height, stand upright with your arm relaxed at your side. The handgrip should be at wrist level. When holding the handgrip, your elbow should have a slight bend (approximately 15-30 degrees).

Image 4.1: Detail of the height adjustment mechanism, showing the pin and multiple adjustment holes.

5. Paké ditangtoskeun

Using the crutch correctly helps maintain stability and reduces the risk of falls.

• Pakem: Hold the handgrip firmly. The ergonomic design provides comfort during use.
• Forearm Cuff: The open cuff design allows for easy release while providing support to the forearm. Ensure your forearm is comfortably seated within the cuff.
• Leumpang: When walking, move the crutch forward simultaneously with the opposite leg. Maintain a steady pace and keep your eyes forward.
• Kasaimbangan: Use the crutch to maintain balance and support your weight as needed. Do not lean heavily on the crutch for prolonged periods if not medically advised.

Image 5.1: The ergonomic handgrip and open forearm cuff designed for comfort and support.

Image 5.2: An individual demonstrating proper posture and use of the crutch while walking.

6. Pangropéa sarta perawatan

Regular maintenance ensures the longevity and safe operation of your crutch.

• beberesih: Wipe the crutch regularly with a damp cloth and mild soap. Avoid abrasive cleaners or solvents that could damage the aluminum finish or plastic components.
• Crutch Tip: Inspect the rubber crutch tip frequently for wear, cracks, or flattening. A worn tip can reduce grip and increase the risk of slipping. Replace worn tips immediately.
• Adjustment Pins: Ensure the adjustment pins move freely and engage fully in the holes. Keep them clean and free of debris.
• Panyimpenan: Store the crutch in a dry place away from extreme temperatures.

Image 6.1: The durable rubber crutch tip, designed for enhanced grip and stability.

7. Panyimpenan jeung Angkutan

The folding design of this crutch makes it convenient for storage and travel.

1. To fold, press the release button or mechanism that secures the two main sections together.
2. Collapse the crutch into its compact form. Once folded, the crutch measures approximately 22.4 inches.
3. The compact size allows for easy storage in a car, closet, suitcase, or backpack.

Image 7.1: The folding mechanism, allowing the crutch to be compactly stored.

8. Cara ngungkulan

If you encounter any issues with your PEPE Mobility Folding Crutch, please refer to the following common solutions:

• Crutch feels unstable or wobbly:
  • Ensure all folding and height adjustment pins are fully engaged and locked.
  • Check for any visible damage to the aluminum frame or plastic components.
• Adjustment pin is stuck or difficult to move:
  • Clean the area around the pin and adjustment holes to remove any dirt or debris.
  • Apply a small amount of silicone-based lubricant if necessary, avoiding oil-based lubricants.
• Crutch tip is slipping:
  • Inspect the crutch tip for wear. Replace if it appears flattened, cracked, or smooth.
  • Ensure the walking surface is dry and clear of obstacles.

If the issue persists or if you observe significant damage, discontinue use and contact customer support.

9. Spésifikasi

10. Garansi jeung Rojongan

For warranty information, technical support, or any questions regarding your PEPE Mobility Folding Crutch, please contact the manufacturer or your retailer. Keep your purchase receipt as proof of purchase.

Manufacturer: IMD SL
