FOXWELL NT1009 Professional Automotive Diagnostic Scanner User Manual

1. Bubuka

The FOXWELL NT1009 is a professional automotive diagnostic scanner designed to provide comprehensive vehicle diagnostics and maintenance functions. This manual provides detailed instructions on how to set up, operate, and maintain your NT1009 device to ensure optimal performance and accurate vehicle analysis.

Gambar 1: Leuwihview of FOXWELL NT1009 key features including ECU Coding, Bi-directional Control, All System Diagnostic, and more.

2. Setup jeung pamakéan munggaran

2.1 Unboxing jeung komponén

Saatos muka bungkusan, pariksa yén sadaya komponén aya:

• FOXWELL NT1009 Diagnostic Tablet
• Bluetooth VCI Dongle
• Kabel Ngecas USB
• Charging Plugs (various types)
• Pituduh Pamaké (manual ieu)

Figure 2: The FOXWELL NT1009 package contents, showing the diagnostic tablet, VCI dongle, charging accessories, and user manual.

2.2 Ngecas Awal

Before first use, fully charge the NT1009 tablet using the provided USB charging cable and appropriate charging plug. The tablet features an 8000mAh battery.

2.3 Connecting the VCI Dongle

The Bluetooth VCI (Vehicle Communication Interface) dongle connects wirelessly to the NT1009 tablet. Locate your vehicle's OBD2 port (typically under the dashboard) and plug in the VCI dongle. Ensure a secure connection.

3. Parentah Operasi

3.1 Powering On and Interface Navigation

Press the power button to turn on the NT1009 tablet. The device features a 10.1-inch color touch screen. Navigate the interface by tapping on icons for different functions such as Diagnostic, Maintenance, New Energy, Update, and Data Manager.

3.2 Wireless Diagnosis via Bluetooth

The NT1009 supports wireless diagnosis through its Bluetooth VCI dongle, allowing for flexible operation around the vehicle. The diagnostic range is up to 33 feet.

3.3 Automatic VIN Acquisition (Auto VIN)

To begin a diagnostic session, select the 'Diagnostic' function. The device can automatically acquire the vehicle's VIN (Vehicle Identification Number) for quick identification and protocol scanning.

3.4 One-click Scan All Systems

After VIN acquisition, the NT1009 can perform a one-click scan of all available vehicle systems to detect fault codes. This provides a comprehensive overview of the vehicle's health.

3.5 Diagnosis Sadaya Sistem Tingkat OE

The NT1009 offers OE-level diagnostic capabilities, allowing access to all electronic control units (ECUs) for detailed fault code reading, clearing, and live data streaming across various systems like Engine, ABS, SRS, Transmission, Body, Chassis, and more.

Figure 3: Illustration of the NT1009's capability to perform all system diagnostics wirelessly via Bluetooth, covering various vehicle modules.

3.6 Bi-directional Control / Active Test

This function allows the user to send commands to vehicle ECUs to perform active tests on components. Examples ngawengku:

• Modulating the accelerator
• Activating the grille shutter
• Turning on/off the fuel heater
• Activating the radiator fan
• Operating the horn

Figure 4: The NT1009 demonstrating bi-directional control, allowing users to activate specific vehicle components for testing.

3.7 ECU Coding

The NT1009 supports advanced ECU coding functions to improve vehicle performance and unlock hidden features. This includes:

• Matching replaced ECUs
• Activating hidden functions (e.g., for Audi, BMW, Skoda, SEAT, Bentley, Bugatti, Lexus, Hino, Mini, Lamborghini, Scion, Toyota, Volkswagen)
• Recoding replaced parts
• Deactivating inconvenient functions
• Offline coding for BMW E Chassis

Figure 5: The NT1009's advanced ECU coding interface, showing options for various vehicle manufacturers.

3.8 Jasa pangropéa

The device offers over 35 maintenance and reset functions, covering more than 10,000 vehicle models. Key services include:

• A/F Adaptation
• Pendaptaran batré
• CVT (Transmisi Variabel Terus-terusan)
• Seat Matching
• Clutch Adaptasi
• DPF Regenerasi
• Robah Basa
• Reset EGR
• Fuel Pressure Test
• Headlamp Penyesuaian
• G Sensor Learn
• Injektor Coding
• Setélan wates
• Reset minyak
• ODS Initialization
• Kasaimbangan kakuatan
• Pompa Suluh Perdana
• Diajar Deui Crankshaft
• Kalibrasi SAS
• Eureun / Mimitian Reset
• Inisialisasi Sunroof
• Kalibrasi gantung
• TPMS Reset
• TPS (Sénsor Posisi Throttle)
• Adaptasi Transmisi
• Turbocharger
• Inisialisasi Jandéla

Figure 6: The NT1009's maintenance service menu, illustrating the extensive list of functions such as ABS bleeding, oil reset, and SAS calibration.

3.9 Grafik Data Langsung

The NT1009 can display live sensor data in a 4-in-1 graph format, allowing for detailed analysis of vehicle performance parameters over time. This helps in diagnosing intermittent issues.

Figure 7: The NT1009's 4-in-1 live data graphing feature, showing multiple sensor readings simultaneously for comprehensive analysis.

3.10 Videoscope Integration

The NT1009 is compatible with the FOXWELL VS300 Videoscope (sold separately). This allows users to inspect hard-to-reach areas of the engine, fuel tank system, and other invisible parts directly on the tablet screen.

Figure 8: The NT1009 in use with a videoscope, demonstrating its capability to inspect internal engine components.

3.11 Generating and Sharing Reports

Diagnostic reports can be saved as PDF files, printed, or shared via Bluetooth or email for easy record-keeping and client communication.

Figure 9: The NT1009's interface for sharing and printing diagnostic reports, highlighting options like Bluetooth and email.

4. Fitur konci

• Kode ECU: Advanced coding capabilities to optimize vehicle performance and activate hidden functions.
• Kontrol dua arah: Perform active tests on various vehicle components.
• Sadaya Diagnosis Sistem: Comprehensive scanning of all vehicle electronic control units at OE-level.
• Layanan Pangropéa 35+: Extensive range of reset and service functions for common vehicle maintenance tasks.
• Cakupan Kandaraan Lega: Supports over 120 vehicle brands, including new energy vehicles.
• Aplikasi Android: Access to various Android applications for enhanced functionality (e.g., browser, email, sound recorder, multitasking).
• Konéktipitas nirkabel: Bluetooth VCI dongle for wireless diagnosis and Wi-Fi for software updates.
• Automatic VIN: Quick vehicle identification through automatic VIN acquisition.
• Live Data Graphing: 4-in-1 graphical display of live sensor data.
• Diagnostic Report Management: Save, print, and share diagnostic reports easily.
• Rojongan multi-basa: Supports 20+ languages for global usability.

5. Pangropéa

5.1 Apdet parangkat lunak

The NT1009 receives regular software updates to expand vehicle coverage, add new functions, and improve performance. Updates can be performed with a single click via Wi-Fi.

Figure 10: The NT1009's one-click Wi-Fi update feature, simplifying the process of keeping the software current.

5.2 Beberesih sareng Panyimpenan

Jaga alatna tetep bersih ku cara ngusap ku cara lemes, damp cloth. Avoid using abrasive cleaners or solvents. Store the NT1009 in its protective case in a dry, cool environment when not in use.

6. Cara ngungkulan

This section addresses common issues you might encounter with your FOXWELL NT1009.

6.1 Alat Teu Dihurungkeun

• Ensure the device is fully charged. Connect it to the charger and wait for at least 30 minutes before attempting to power on again.
• Check the power button for any obstruction or damage.

6.2 VCI Dongle Not Connecting

• Verify the VCI dongle is securely plugged into the vehicle's OBD2 port.
• Ensure the vehicle's ignition is on (engine can be off).
• Check the Bluetooth settings on the NT1009 tablet to ensure Bluetooth is enabled and the VCI dongle is paired.
• Restart both the tablet and the vehicle (turn ignition off and on).

6.3 Unable to Perform Diagnostic Functions

• Confirm the VCI dongle is properly connected and communicating with the tablet.
• Pastikeun ignition kendaraan dihurungkeun.
• Verify that the vehicle make, model, and year are correctly selected in the diagnostic software.
• Check for any pending software updates for your vehicle's specific software.
• Upami masalahna tetep, hubungi dukungan téknis.

6.4 Kinerja Leungit atanapi Beku

• Tutup aplikasi anu teu dipikabutuh anu dijalankeun di latar tukang.
• Clear the device's cache or perform a factory reset (back up data first).
• Pastikeun aya rohangan panyimpen anu cekap.

7. Spésifikasi

Figure 11: Visual representation of the NT1009's hardware specifications, highlighting its 10.1-inch screen, Android 9.0, and 8000mAh battery.

8. Rojongan & Garansi

FOXWELL is committed to providing excellent customer service and support for the NT1009 diagnostic scanner.

8.1 Apdet parangkat lunak

Enjoy 2 years of free software updates to keep your device current with the latest vehicle models and diagnostic functions.

8.2 Rojongan Téknis

Remote technical support is available to assist with any operational or technical issues. Our after-sales service operates 24 hours a day, 7 days a week.

8.3 Return and Refund Policy

A 90-day return and refund policy is offered for your peace of mind.

8.4 Eupan Balik Online

You can provide feedback directly through the device or our official channels for continuous improvement.

Figure 12: Information on FOXWELL's customer support, including free updates, 24/7 after-sales service, and return policy.
