1. Produk Langkungview
The Zafferano Pina Lamp is a portable, rechargeable, and wireless table lamp designed for both indoor and outdoor environments. It features a touch control system for adjusting light intensity and color temperature, and is constructed from durable materials.
Image 1.1: The Zafferano Pina Lamp in black, highlighting its elegant and minimalist design.
2. Eusi Paket
Pastikeun sadaya item aya dina bungkusan:
- Zafferano Pina Lamp (Model LD1650D3)
- Tempat ngecas
- adaptor kakuatan / carjer
3. Persiapan sareng Pangisian Daya Awal
- Buka bungkus Lamp: Carefully remove the Pina Lamp, charging station, and power adapter from the packaging.
- Sambungkeun Stasion Pangecas: Connect the power adapter to the charging station, then plug the adapter into a suitable power outlet.
-
Tempat anu Lamp on the Charging Station: Position the Pina Lamp onto the charging station. Ensure proper contact for charging to begin. The lamp's indicator light (if present) may change to signify charging status.
Image 3.1: The Pina Lamp placed on its charging base, ready for recharging.
- Muatan Awal: For optimal battery performance, fully charge the lamp before its first use. A full charge typically takes 6-7 hours. The lamp provides at least 12 hours of operation on a full charge.
4. Parentah Operasi
The Pina Lamp features intuitive touch controls located on its base.
- Hurungkeun/Pareuman: Lightly touch the control area on the lampdasar pikeun muterkeun lamp hurung atawa pareum.
- Adjust Light Intensity (Dimmer): Sedengkeun lamp is on, press and hold the touch control area to cycle through different brightness levels. Release your finger when the desired intensity is reached.
- Robah Suhu Warna: Kalayan lamp on, quickly tap the touch control area to switch between available color temperatures: 2200 K (warm), 2700 K (neutral warm), and 3000 K (cool white).
-
Pamakéan outdoor: The Pina Lamp has an IP54 protection rating, making it suitable for outdoor use. Ensure the charging port is dry before charging if used outdoors.
Image 4.1: The Pina Lamp providing ambient lighting for an outdoor setting.
5. Pangropéa
- beberesih: Ngusap lamp with a soft, dry cloth. For stubborn marks, use a slightly damp lawon lajeng garing tuntas. Ulah make cleaners abrasive atawa pangleyur.
- Perawatan batré: Anu lamp's control system monitors battery life to optimize charging and prevent overcharging. To prolong battery life, avoid fully discharging the lamp frequently. If storing for an extended period, charge the battery to approximately 50% and recharge every 3-6 months.
- Ngagantian batré: The battery is replaceable. For battery replacement services, please contact Zafferano customer support or an authorized service center.
- Panyimpenan: Nyimpen lamp in a cool, dry place away from direct sunlight and extreme temperatures when not in use for long periods.
6. Cara ngungkulan
| Masalah | Mungkin Cukang lantaranana | Solusi |
|---|---|---|
| Lamp henteu hurung. | Batré béak. | Teundeun lamp on the charging station and allow it to charge for several hours. |
| Lamp henteu hurung. | Charging station not powered. | Ensure the power adapter is securely plugged into both the charging station and a working power outlet. |
| Light intensity or color temperature cannot be adjusted. | Incorrect touch control gesture. | For intensity, press and hold. For color temperature, quickly tap. Ensure your finger covers the touch control area. |
| Lamp flickers or turns off unexpectedly. | batré lemah. | Ngecas deui lamp pinuh. |
7. Spésifikasi
| Nomer modél | LD1650D3 |
| merek | Zafferano |
| Ukuran produk (D x W x H) | 10.5D x 10.5W x 29H séntiméter |
| Item Beurat | 0.4 kg |
| Bahan | Aluminium (Base), Polycarbonate (Shade) |
| Tipe rengse | Dicét |
| Tipe Sumber Cahaya | LED |
| Wattage | 2.2 watt |
| Voltage | 5 Volt (DC) |
| Sumber Daya | Batré Powered |
| Kahirupan batré | At least 12 hours (on full charge) |
| Waktu Ngecas | 6-7 hours (at 1A) |
| Suhu Warna | 2200 K, 2700 K, 3000 K |
| Métode kontrol | Toél Dimmer |
| Peunteun IP | IP54 (Suitable for outdoor use) |
| Komponén Kaasup | Charging station with charger |
Image 7.1: Technical drawing illustrating the dimensions of the Pina Lamp.
8. Garansi jeung Rojongan
Zafferano products are manufactured to high-quality standards. For warranty information, technical support, or service inquiries, please contact your retailer or visit the official Zafferano websitus. Punten tahan bukti pameseran anjeun pikeun klaim garansi.
For further assistance, please refer to the contact information provided with your purchase or on the Zafferano official websitus.
