1. Bubuka
The Pekatherm US20TD heating pad is designed to provide gentle and even warmth to your body, promoting relaxation and relieving muscle pain. This manual provides essential information for the safe and effective use, maintenance, and troubleshooting of your heating pad. Please read it thoroughly before first use and keep it for future reference.
Figure 1: Pekatherm US20TD Universal Electric Heating Pad with its removable cover and controller.
2. Parentah Kasalametan
Pikeun mastikeun operasi anu aman sareng nyegah tatu atanapi karusakan, punten taat kana pedoman kaamanan ieu:
- Ulah make while sleeping or on an unconscious person.
- Ulah make on infants, children, or persons with reduced physical, sensory, or mental capabilities unless supervised.
- Hindari lipatan atau krepitasiasing the heating pad excessively during use, as this may cause overheating.
- Ulah nyelapkeun pin or other metallic objects into the heating pad.
- Ulah make if the heating pad or power cord is damaged. Contact customer support for repair or replacement.
- Cabut colokan the heating pad from the power outlet when not in use or before cleaning.
- The heating pad features a double temperature control system jeung an automatic shut-off after 120 minutes pikeun kaamanan ditingkatkeun.
- This product is for personal use and not intended for medical or commercial purposes without professional guidance.
3. Produk Langkungview
The Pekatherm US20TD heating pad is designed for versatile application across various body parts to alleviate muscle tension and pain. It comes with a user-friendly remote control for temperature adjustment and a removable, washable cover for hygiene.
komponén:
- Heating Pad Unit (40 x 30 cm)
- Removable Polyester Cover
- Detachable Control Unit with Power Cord
Gambar 2: Top-handap view of the heating pad showing the integrated control unit.
4. Setélan
Setting up your Pekatherm US20TD heating pad is quick and easy.
- Ngabongkar: Carefully remove the heating pad and all its components from the packaging.
- mariksa: Check the heating pad, control unit, and power cord for any signs of damage. Do not use if damaged.
- Pasang Panutup: Ensure the removable polyester cover is properly fitted onto the heating pad.
- Sambungkeun Unit Kontrol: Connect the detachable control unit's cord securely to the heating pad's connection point.
5. Parentah Operasi
Follow these steps to operate your heating pad:
- panempatan: Place the heating pad firmly on the part of your body where heat therapy is desired. Its flexible design allows it to adapt to various body contours, such as the back, neck, or abdomen.
- Daya Hurung: Plug the power cord of the control unit into a standard electrical outlet (230 Volts).
- Pilih Suhu: Use the control unit to select your desired temperature level. The pad offers 3 temperature settings. Start with the lowest setting and increase gradually if more warmth is needed.
- Tenang: Once the desired temperature is set, get comfortable and allow the soothing heat to work. The pad will automatically shut off after 120 minutes of continuous operation for safety.
- Pareum listrik: To turn off the heating pad manually, use the control unit. Always unplug the unit from the wall outlet after use.
Figure 3: The control unit allows for easy temperature selection and power management.
Gambar 4: Kelample of heating pad application for muscle relief.
6. Pangropéa
Pangropéa anu leres mastikeun umur panjang sareng kabersihan bantalan pemanas anjeun.
beberesih:
- Always unplug the heating pad from the power outlet before cleaning.
- The polyester cover is removable and washable. It can be washed by hand or machine. Refer to the care label on the cover for specific washing instructions (e.g., temperature, cycle).
- Do not wash the heating pad unit itself. If it becomes soiled, wipe it gently with a damp cloth and allow it to air dry completely before re-use.
- Do not dry clean, bleach, or iron the heating pad or its cover.
Figure 5: The removable cover is machine washable for easy cleaning.
Panyimpenan:
- Ensure the heating pad is completely cool and dry before storing.
- Store the heating pad in a cool, dry place, away from direct sunlight and moisture.
- Avoid placing heavy objects on top of the stored heating pad to prevent damage.
7. Cara ngungkulan
If you encounter any issues with your Pekatherm US20TD heating pad, please refer to the following common problems and solutions:
| Masalah | Mungkin Cukang lantaranana | Solusi |
|---|---|---|
| Pad pemanasan teu hurung. | Not plugged in correctly; Power outlet issue; Damaged cord/control unit. | Ensure the power cord is securely plugged into a working outlet. Test the outlet with another device. If the cord or control unit is damaged, do not use; contact customer support. |
| Heating pad is not heating sufficiently. | Incorrect temperature setting; Automatic shut-off activated. | Increase the temperature setting using the control unit. The pad automatically shuts off after 120 minutes; turn it off and on again if needed. |
| Heating pad feels too hot. | Setélan suhu teuing. | Decrease the temperature setting using the control unit. Discontinue use if discomfort persists. |
| Pareum otomatis kajadian gancang teuing. | Overheating protection activated; Internal fault. | Ensure the pad is not folded or covered in a way that restricts heat dissipation. If the issue persists, contact customer support. |
If the problem persists after trying these solutions, please contact Pekatherm customer support. Do not attempt to repair the device yourself.
8. Spésifikasi
| Fitur | Rincian |
|---|---|
| Ngaran modél | Pekatherm Universal Heating Pad (All Zones) |
| Nomer Modél Item | US20TD |
| merek | Pekatherm |
| Ukuran (L x W x H) | 40 x 30 x 0.3 cm (15.7 x 11.8 x 0.1 inci) |
| Beurat | 400 gram (0.88 lbs) |
| Kakuatan | 90 Watt |
| Voltage | 230 volt |
| Jumlah Setélan Suhu | 3 |
| Bahan | 100% Poliéster |
| Fitur husus | Automatic Shut-off (after 120 minutes), Washable Cover, Double Temperature Control |
| Warna | Amber |
| Negara asal | Spanyol |
9. Garansi jeung Rojongan
For information regarding warranty coverage, product registration, or technical support, please contact Pekatherm customer service directly.
- Refer to the product packaging or the official Pekatherm websitus pikeun detil kontak.
- When contacting support, please have your model number (US20TD) and purchase information ready.
Pekatherm Official Websitus: www.pekatherm.com (Catetan: Ieu mangrupikeun pananda tempat URL sakumaha euweuh rojongan husus URL was provided in the JSON. Users should verify the correct official websitus.)
