Joyoung DJ13M-D81SG Soymilk Maker Instruction Manual

1. Bubuka

Thank you for choosing the Joyoung DJ13M-D81SG Soymilk Maker. This appliance is designed to provide a convenient and efficient way to prepare fresh soymilk and various other beverages and foods. It features an innovative "broken-free filter system" for enhanced crushing and a three-dimensional heating technology for optimal nutrient release. This manual provides essential information for safe operation, maintenance, and troubleshooting to ensure you get the best performance from your machine.

The DJ13M-D81SG offers a range of functions including Soymilk, Double Thick Soymilk, Fast Soymilk, Five Grains, Porridge, Juice, Baby Food, Soup, and Mung Bean, catering to diverse nutritional needs.

2. Parentah Kasalametan penting

Please read all instructions carefully before using the appliance and retain them for future reference.

• Salawasna mastikeun voltage of your power supply matches the rating label on the appliance.
• Do not immerse the main unit (head with motor and heating element) in water or any other liquid to prevent electric shock.
• Jauhkeun alat tina jangkauan barudak. Pengawasan anu ketat diperyogikeun nalika alatna dianggo caket barudak.
• Entong ngajalankeun alat nganggo kabel atanapi colokan anu ruksak, atanapi saatos alatna teu tiasa dianggo atanapi rusak dina cara naon waé.
• Hindarkeun kontak sareng bagian anu gerak.
• Entong nganggo kantétan anu henteu disarankeun atanapi dijual ku produsén.
• Cabut colokan tina stop kontak nalika henteu dianggo, sateuacan dipasang atanapi nyabut bagian, sareng sateuacan beberesih.
• Ulah make di luar.
• Entong ngantepkeun kabelna ngagantung dina ujung méja atanapi konter, atanapi nyabak permukaan anu panas.
• Ulah nempatkeun dina atawa deukeut gas panas atawa burner listrik, atawa dina oven dipanaskeun.
• Sok pasangkeun heula colokan ka alat, teras colokkeun kabelna kana stop kontak témbok. Pikeun megatkeun sambungan, balikkeun sagala kadali kana "off", teras cabut colokan ti stop kontak témbok.
• Entong nganggo alat pikeun tujuan anu sanés.
• Ati-ati pisan nalika mindahkeun alat anu ngandung cairan panas.
• Alatna ngan ukur kanggo panggunaan rumah tangga.

3. Komponén produk

Familiarize yourself with the main parts of your Joyoung Soymilk Maker.

Figure 3.1: Main Unit and Grinding Head. This image displays the golden-colored jug (main unit) and the detachable stainless steel grinding head. The grinding head contains the motor and blades for processing ingredients.

Figure 3.2: Grinding Blades. A nutup-up view of the stainless steel grinding blades and filter system, designed for efficient crushing without the need for external filtering.

Figure 3.3: Interior Jug with Capacity Markings. The interior of the stainless steel jug showing the 900mL, 1100mL, and 1300mL capacity lines for precise ingredient measurement.

4. Setup jeung pamakéan munggaran

1. Ngabongkar bungkusan: Sacara saksama miceun sadaya bahan bungkusan sareng mariksa alat upami aya karusakan.
2. Bersihan awal: Before first use, clean all parts that will come into contact with food. Refer to the "Cleaning and Maintenance" section for detailed instructions. Ensure the main unit (head) is wiped with a damp lawon sarta henteu dicelup dina cai.
3. panempatan: Place the soymilk maker on a stable, flat, and heat-resistant surface. Ensure there is adequate ventilation around the appliance.
4. Sambungan Daya: Plug the power cord into a standard 120 Volt electrical outlet.

5. Parentah Operasi

The Joyoung DJ13M-D81SG offers a variety of functions accessible via its control panel.

Gambar 5.1: Panel Kontrol. This image shows the control panel with various function buttons, including "Multifunction", "Soymilk function", and "Start/Cancel". Functions include Porridge, Juice, Baby Food, Pottage, Mung Bean, Soymilk, Five Grains, Double Thick, and Fast Soymilk.

5.1. Léngkah-léngkah Operasi Umum

1. Nyiapkeun Bahan: Measure and prepare your ingredients according to the recipe or desired function. For soymilk, use dry or pre-soaked soybeans.
2. Tambahkeun Bahan: Place the prepared ingredients into the stainless steel jug.
3. Tambahkeun cai: Fill the jug with water up to the desired capacity line (900mL, 1100mL, or 1300mL) as indicated on the interior of the jug. Do not exceed the maximum fill line.
4. Pasang Kepala Penggilingan: Securely place the grinding head onto the jug. Ensure it is properly seated and locked into position.
5. Pilih Fungsi: Plug in the appliance. On the control panel, select your desired function (e.g., "Soymilk", "Porridge", "Juice").
6. Mimitian: Press the "Start/Cancel" button to begin the selected program. The appliance will automatically process and heat the ingredients.
7. Parantosan: Once the program is complete, the appliance will typically emit a signal. Unplug the appliance and carefully remove the grinding head.
8. ngalayanan: Pour the prepared beverage or food into a serving container.

5.2. Specific Functions Overview

The DJ13M-D81SG offers a wide range of functions:

Gambar 5.2: Fungsi Leuwihview. This image illustrates the various food and beverage types that can be prepared, including original soymilk, five grains soymilk, thick soymilk, fast soymilk, porridge, juice, baby food, and soup.

• Soymilk (Dry Bean / Soaked Bean): For preparing fresh soymilk from either dry or pre-soaked soybeans. The "broken-free filter system" ensures a smooth consistency.
• Double Thick Soymilk: Creates a richer, creamier soymilk.
• Fast Soymilk: A quicker cycle for soymilk preparation.
• Five Grains: For preparing nutritious beverages from a mix of grains.
• Bubur: Ideal for cooking various types of porridge.
• Jus: For blending fruits and vegetables into fresh juices.
• Dahareun orok: Designed for preparing smooth and nutritious baby food supplements.
• Sup: For making various types of soups.
• Mung Bean: Specifically for preparing mung bean beverages or soups.

The appliance utilizes a patented intelligent heating system with 5 steps to ensure thorough cooking and full nutrient release.

Figure 5.3: Three-Dimensional Heating. An illustration demonstrating the circular and bottom heating elements that ensure even cooking and prevent scorching, leading to a richer taste.

6. beberesih sarta Pangropéa

Always unplug the appliance before cleaning. Allow the appliance to cool down completely before handling.

Figure 6.1: Cleaning Guide. This image provides a visual and textual guide for cleaning the soymilk maker, detailing how to clean the head and the jug.

6.1. Cleaning the Head

• Clean any ingredient residue stuck to the lower part of the grinding head.
• Awas: Do not let water enter the head and coupler. Do not immerse the head into water or wash the head directly to prevent short circuits.
• Use a wet cloth to wipe the head clean.
• If cleaning cannot be done timely, pour some water into the jug and run the "Easy Wash" function if available, or a short cycle with water only.

6.2. Cleaning the Jug

• Clean the jug carefully after each use.
• Awas: Do not immerse the base of the jug into water.
• For stubborn stains or discoloration (e.g., on the SUS jar), use vinegar to clean.

6.3. Panyimpenan

• After cleaning, ensure the appliance is completely dry.
• Store the appliance in a dry and airy place, away from direct sunlight and moisture.

7. Cara ngungkulan

If you encounter issues with your Joyoung Soymilk Maker, please refer to the following common problems and solutions:

Lamun masalah persists sanggeus nyobian solusi ieu, mangga ngahubungan rojongan customer.

8. Spésifikasi produk

9. Garansi jeung Rojongan

This Joyoung DJ13M-D81SG Soymilk Maker comes with a garansi produsén sataun (applicable in Canada, please check local warranty terms for other regions).

For warranty claims, technical support, or any questions regarding the operation or maintenance of your appliance, please contact Joyoung customer service. Please have your model number (DJ13M-D81SG) and proof of purchase ready when contacting support.

Contact information for customer support is typically found on the product packaging or the official Joyoung websitus.
