iCarsoft BMM V3.0 Bidirectional Diagnostic Tool

1. Bubuka

This manual provides detailed instructions for the operation and maintenance of the iCarsoft BMM V3.0 Diagnostic Tool. This device is designed to assist in diagnosing and performing various service functions on BMW, Mini, and Rolls-Royce vehicles. Please read this manual thoroughly before using the device to ensure proper and safe operation.

2. Produk Langkungview

The iCarsoft BMM V3.0 is a professional diagnostic scanner offering comprehensive system diagnostics and advanced service functions for specific vehicle brands. It is engineered to provide in-depth analysis and maintenance capabilities.

Image: The iCarsoft BMM V3.0 diagnostic tool, showcasing its user interface and main menu options.

Fitur konci:

• Sadaya Diagnostik Sistem: Comprehensive scanning of all available vehicle systems.
• Bi-directional Control/Active Test: Ability to send commands to vehicle systems and components.
• Fungsi Palayanan Ekstensif: Includes Oil Reset, EPB, SAS, BMS, ETC, D-P.Filter, ABS Bleeding, Injector Coding, TPMS Reset, and more.
• Kode ECU: For performance optimization, fuel efficiency, and software updates.
• Battery Test & Registration: Assess battery health and register new batteries.
• Fungsi OBDII lengkep: Standard OBDII diagnostic capabilities.

3. Setélan

3.1 Nyambungkeun Alat

Locate the 16-pin OBDII diagnostic port in your vehicle, typically found under the dashboard on the driver's side. Connect the diagnostic tool's OBDII adapter securely to this port. Ensure the connection is firm.

3.2 Mimiti Power-Up

Once connected to the vehicle's OBDII port, the device will typically power on automatically. Follow the on-screen prompts to select your vehicle's make and model.

3.3 Apdet parangkat lunak

It is recommended to keep the device's software updated to ensure access to the latest vehicle models and functions. Updates are performed via a PC. Refer to the 'Maintenance' section for detailed update instructions.

3.4 Cék kasaluyuan

Sateuacan meuliasing or performing specific functions, verify compatibility with your vehicle model. This can be done through the manufacturer's official websitus.

Image: Instructions on how to check vehicle compatibility and available functions on the iCarsoft websitus.

4. Parentah Operasi

4.1 Napigasi Umum

The device features a user-friendly interface with directional buttons (up, down, left, right), 'ENTER' for selection, 'BACK' to return, and function keys (F1, F2) for quick access to specific features. Navigate through menus using the arrow keys and confirm selections with 'ENTER'.

4.2 Otomatis VIN Scan

The Auto VIN function allows the tool to automatically detect and identify vehicle information. If auto-scan is not supported for your vehicle, manual VIN input or selection is available.

Image: The Smart Auto VIN and Auto Scan feature, demonstrating how the tool automatically identifies vehicle information.

4.3 Diagnostik

This function performs a comprehensive scan of all vehicle systems to identify fault codes and provide detailed reports.

• Baca/Hapus Kodeu: Retrieve and erase diagnostic trouble codes (DTCs).
• Aliran Data Langsung: View real-time data parameters from various sensors and modules.
• Pilarian DTC: Access a built-in library for definitions of diagnostic trouble codes.
• Vehicle Health Report: Generate a summary of the vehicle's diagnostic status.

Gambar: Leuwihview of all system diagnostics capabilities, illustrating the tool's ability to scan various vehicle systems and perform core diagnostic functions.

4.4 Service Functions (Resets)

The BMM V3.0 offers a wide range of service reset functions to assist with vehicle maintenance.

• Service Reset Oli: Ngareset sistem umur oli mesin.
• EPB (Electronic Parking Brake Service): Deactivates and activates the brake control system.
• SAS (Steering Angle Calibration Service): Performs calibration for the Steering Angle Sensor.
• BMS (Battery Management System Service): Registers new batteries and clears fault information.
• ETC (Electronic Throttle Control Service): Resets the throttle actuator.
• D-P.Filter Service: Performs Diesel Particulate Filter regeneration.
• BLD (ABS Bleeding Service): Bleeds the brake system.
• INJ (Injector Coding Service): Kode angka injector anyar.
• TPMS (Tire Pressure Monitor System Service): Ngareset sistem pangawas tekanan ban.
• BSC (Body Stability Control Service): Performs body stability control system functions.
• ECM (Engine Control Service): Engine control module related services.
• TCM (Transmission Control Service): Transmission control module related services.
• IDL (Engine Idle Service): Adjusts engine idle parameters.
• MIS (Miscellaneous): Other various service functions.

Image: A visual representation of the extensive list of maintenance services available through the diagnostic tool.

4.5 Bi-directional Control / Active Test

This feature allows the diagnostic tool to send commands to vehicle systems and components to perform specific tests, verifying their functionality. This is useful for pinpointing malfunctions.

• Tés Injektor: Activates individual injectors.
• Uji Pompa Bahan Bakar: Commands the fuel pump to operate.
• Window Test: Controls window movement.
• Uji Kipas Pendingin: Activates the cooling fan.
• HVAC Test: Tests heating, ventilation, and air conditioning components.
• Wiper Test: Controls wiper operation.
• Door Lock Test: Tests door lock mechanisms.
• Horn Test: Activates the vehicle horn.

Image: A visual explanation of the bi-directional control and active test capabilities, showing how the tool interacts with vehicle components.

4.6 ECU Coding

ECU Coding allows for advanced vehicle customization and optimization. This function can:

• Improve engine power performance.
• Optimize fuel efficiency.
• Match new hardware units to the vehicle.
• Customize driving modes.
• Fix and update original software bugs.

Image: The ECU Coding feature, highlighting its benefits for vehicle performance and software management.

4.7 Fungsi OBDII Lengkep

The tool supports all standard OBDII diagnostic modes, providing essential engine and emission-related information.

• Baca/Hapus DTCs: Standard diagnostic trouble code management.
• Data Langsung: Real-time sensor data.
• O2 Sensor Tests: Ngawaskeun kinerja sénsor oksigén.
• Kesiapan I / M: Mariksa kesiapan sistem émisi.
• Freeze Data Frame: Captures vehicle conditions at the time a fault code was set.
• Baca Inpormasi Kendaraan: Displays VIN, CID, CVN.
• Tes Monitor Onboard: Accesses results of on-board diagnostic monitoring tests.
• Tés EVAP: Tests the Evaporative Emission System.

Gambar: A komprehensif view of the full OBDII functions supported by the iCarsoft BMM V3.0.

4.8 Battery Test and Registration

The tool includes functions to assess the health of your vehicle's battery and to properly register a new battery with the vehicle's Battery Management System (BMS).

Image: The battery test and registration feature, illustrating the tool's role in managing vehicle battery health.

5. Pangropéa

5.1 Perawatan Alat

Keep the device clean and free from dust and moisture. Store it in a dry, cool environment when not in use. Avoid dropping the device or exposing it to extreme temperatures.

5.2 Apdet parangkat lunak

Regular software updates are crucial for maintaining optimal performance and compatibility with new vehicle models. Updates are free for life and can be performed via a PC.

• Sambungkeun alat ka komputer nganggo kabel USB nu disadiakeun.
• Download and install the update client software from the iCarsoft official websitus.
• Follow the on-screen instructions in the update client to download and install the latest software version onto your device.

Image: The process of updating the diagnostic tool's software via a personal computer.

6. Cara ngungkulan

If you encounter issues with your iCarsoft BMM V3.0, consider the following:

• Alat Teu Dihurungkeun: Ensure the OBDII connector is securely plugged into the vehicle's diagnostic port. Check the vehicle's battery status.
• Kasalahan Komunikasi: Verify that the vehicle's ignition is on. Ensure the OBDII connector is properly seated. Try connecting to a different vehicle to rule out a vehicle-specific issue.
• Fungsi Teu Gawé: Some functions are vehicle-specific. Refer to the compatibility list on the iCarsoft website for your specific vehicle model. Ensure the software is up to date.
• Layar beku: Disconnect the device from the vehicle and reconnect. If the issue persists, perform a software update.
• Vehicle After 2023: For vehicles manufactured after 2023, contact iCarsoft support for compatibility verification as some newer models may have diagnostic limitations.
• Incorrect OBDII Port: The device comes with a 16-pin OBD2 adapter. If your vehicle has a 14-pin diagnostic socket, contact iCarsoft for a solution.

For persistent issues, please contact iCarsoft technical support.

7. Spésifikasi

8. Garansi jeung Rojongan

iCarsoft is committed to providing reliable diagnostic tools and comprehensive customer support.

Gambar: Hiji leuwihview of iCarsoft's lifetime service commitment for the BMM V3.0 diagnostic tool.

Garansi:

• Garansi 1 Taun: Ngawengku cacad produksi.
• Apdet Parangkat Lunak Gratis Saumur Hirup: Ensures your device always has the latest features and vehicle coverage.
• Lifetime Hardware Free Repair: Repair services for hardware issues (excluding logistics costs).

Bantosan Téknis:

• Rojongan Téknis Hirupna: Access to technical engineers for assistance.
• 24/7/365 After-Sale Service: Continuous support for any queries or issues.

For support, please visit the official iCarsoft websitus atanapi ngahubungan layanan palanggan maranéhna.
