Bubuka
This manual provides essential information for the safe and effective use of your Sigma 24-70mm f/2.8 DG OS HSM Art Lens for Nikon F. This large-diameter standard zoom lens is designed for high-megapixel digital cameras, featuring three SLD (Special Low Dispersion) glass elements and four aspherical lens elements to minimize optical aberrations and deliver high-quality images.
Naon dina Box
Upon opening your Sigma 24-70mm f/2.8 DG OS HSM Art Lens package, you should find the following items:
- Sigma 24-70mm f/2.8 DG OS HSM Art Lens
- Tiung lénsa
- Cap Lénsa Hareup
- Tutup Lénsa Rear
- Kasus Lensa
Produk Leuwihview
The Sigma 24-70mm f/2.8 DG OS HSM Art Lens is engineered for robust performance and functionality. Key features include:
- Optical Stabilizer (OS) Functionality: Helps reduce camera shake for sharper images.
- Hyper Sonic Motor (HSM): Provides fast, quiet, and accurate autofocus.
- Durable Lens Barrel: Designed for high rigidity and longevity.
- Constant f/2.8 Aperture: Maintains a bright aperture throughout the zoom range for consistent low-light performance and depth of field control.
Gambar 1: Hareupeun view of the Sigma 24-70mm f/2.8 DG OS HSM Art Lens. This image shows the lens from the front, highlighting the large front element and the zoom ring.
Gambar 2: Angled view of the Sigma 24-70mm f/2.8 DG OS HSM Art Lens with its included lens hood attached. The lens hood helps to prevent flare and protect the front element.
Disetél
Ngapasangkeun Lénsa kana Kaméra Anjeun
- Pastikeun kaméra anjeun pareum.
- Cabut tutup lénsa tukang tina lénsa sareng tutup awak kaméra tina kaméra anjeun.
- Align the mounting index on the lens with the mounting index on the camera body.
- Selapkeun lénsa kana kaméra mount jeung balikkeun kana jarum jam nepi ka clicks kana tempatna. Ulah maksakeun lensa.
- Attach the lens hood by aligning its mark with the mark on the front of the lens, then twist until it locks.
Gambar 3: Sisi view of the Sigma 24-70mm f/2.8 DG OS HSM Art Lens securely mounted on a camera body. This view shows the lens controls and the camera's grip.
Gambar 4: Top view of the Sigma 24-70mm f/2.8 DG OS HSM Art Lens mounted on a camera body. This perspective highlights the lens's profile and how it integrates with the camera.
Parentah Operasi
Focus Mode Switch (AF/MF)
The lens features a switch to select between Autofocus (AF) and Manual Focus (MF). For automatic focusing, set the switch to AF. For manual focusing, set the switch to MF and rotate the focusing ring to adjust focus. The autofocus performance is highly effective, even with older camera bodies.
Optical Stabilizer (OS) Switch
The Optical Stabilizer (OS) function helps to compensate for camera shake, allowing for sharper images, especially in low light or at slower shutter speeds. Use the OS ON/OFF switch on the lens barrel to activate or deactivate this feature as needed. This feature is beneficial for handheld shooting.
Ngazum Cingcin
Rotate the zoom ring to change the focal length between 24mm and 70mm. The constant f/2.8 aperture ensures consistent exposure and depth of field characteristics across the entire zoom range. The zoom ring operates smoothly, providing precise control over your composition.
Pangropéa
- Ngabersihan lensa: Use a soft, lint-free cloth and a specialized lens cleaning solution to gently wipe the lens elements. Avoid touching the glass with your fingers.
- Ngaleungitkeun lebu: Anggo sikat blower pikeun miceun lebu tina permukaan lénsa.
- Panyimpenan: When not in use, store the lens with both front and rear caps attached, preferably in its lens case, in a cool, dry place away from direct sunlight and extreme temperatures.
- Hindarkeun Uap: Do not expose the lens to rain, water, or high humidity. If it gets wet, wipe it immediately with a dry cloth.
Pamérésan masalah
| Masalah | Mungkin Cukang lantaranana | Solusi |
|---|---|---|
| Lensa teu fokus | Focus mode set to MF; dirty lens contacts; insufficient light. | Set focus mode to AF. Clean lens and camera contacts. Use adequate lighting or a flash. |
| Gambar blur | Camera shake; incorrect focus; dirty lens elements. | Ensure OS is ON (if applicable). Re-focus. Clean lens elements. Use a faster shutter speed or tripod. |
| Lensa teu dipikawanoh ku kaméra | Improperly mounted lens; dirty electrical contacts. | Re-mount the lens securely. Clean the electrical contacts on both the lens and camera body. |
spésifikasi
- merek: Sigma
- Jumlah modél: 576955
- Panjang fokus: 24-70mm
- Aperture maksimum: f/2.8
- Jenis lensa: Zum
- Pamasangan anu cocog: Nikon F
- Optical Stabilization (OS): Sumuhun
- Hyper Sonic Motor (HSM): Sumuhun
- Ukuran produk: 3.5 x 4.2 x 4.2 inci
- Beurat barang: 2 pon
- Batré: 1 Nonstandard Battery (required for some functions, typically for OS)
Garansi sareng Rojongan
For warranty information, product registration, and technical support, please refer to the official Sigma website or contact your local authorized Sigma dealer. Keep your proof of purchase for warranty claims.
Pabrikan: Sigma Corporation of America
