Activa Mastercook CALIFORNIA Gas Grill User Manual

Bubuka

Thank you for choosing the Activa Mastercook CALIFORNIA Gas Grill. This manual provides essential information for the safe assembly, operation, maintenance, and troubleshooting of your new gas grill. Please read these instructions carefully before using the appliance and retain them for future reference.

The Activa Mastercook CALIFORNIA Gas Grill is designed for outdoor use, offering a convenient and efficient way to prepare grilled dishes. It features a robust design with three main burners and a side burner for versatile cooking, along with an integrated thermometer for optimal temperature control and wheels for easy mobility.

Gambar: Hareupeun view of the Activa Mastercook CALIFORNIA Gas Grill with the lid and cabinet doors open, showcasing the cooking grates, side burner, and internal storage.

Émbaran Kasalametan

PERHATOSAN: Gagalna nuturkeun parentah kaamanan ieu bisa ngakibatkeun tatu serius atawa maot.

• This grill is for outdoor use only. Do not operate indoors or in enclosed spaces.
• Maca sadaya pitunjuk sateuacan dirakit sareng dianggo.
• Tetep barudak jeung piaraan jauh ti grill dina sepanjang waktos.
• Ulah nyimpen atawa make béngsin atawa cairan kaduruk séjén atawa uap di sabudeureun ieu atawa alat sejenna.
• Salawasna pastikeun ventilasi anu leres.
• Check for gas leaks before each use. Use a soapy water solution; never use an open flame.
• Ulah ninggalkeun grill unattended bari dipaké.
• Ensure the gas cylinder is stored upright and secured.
• Anggo sarung tangan pelindung nalika nanganan komponén panas.
• Keep the area around the grill clear and free from combustible materials.

Eusi pakét

Before beginning assembly, ensure all parts are present and undamaged. The main components included with your Activa Mastercook CALIFORNIA Gas Grill are:

• Gas Grill Unit (main body with burners and side burner)
• Cast Iron Grate (50x37 cm)
• Thermometer (integrated into the lid)
• Burner Covers / Heat Diffusers
• Rak samping
• Roda pikeun mobilitas
• Assembly Hardware and Tools (may vary)

Gambar: Interior view of the grill, highlighting the cast iron cooking grates and the stainless steel burner covers.

Setup sareng Majelis

Assembly is required for this gas grill. Follow the detailed instructions provided in the separate assembly manual for step-by-step guidance. Ensure all connections are secure and leak-free before first use.

Léngkah-léngkah Majelis Utama:

1. Ngabongkar bungkusan: Sacara saksama miceun sadaya komponén tina bungkusan.
2. Majelis Dasar: Assemble the main frame and attach the wheels.
3. Pamasangan Kabinet: Mount the cabinet panels and doors.
4. Grill Body Placement: Secure the main grill body onto the assembled base.
5. Side Shelves and Side Burner: Attach the side shelves and connect the side burner gas line.
6. Komponén internal: Place burner covers and cooking grates inside the grill.
7. Sambungan Gas: Connect the gas regulator and hose to the grill's inlet and to a suitable gas cylinder (not included). Ensure the connection is tight.
8. Uji bocor: Perform a leak test on all gas connections using a soapy water solution. Bubbles indicate a leak. Tighten connections or replace parts as necessary.

Gambar: Detil view of the control panel with burner knobs and the integrated side burner, illustrating the components involved in gas connection and operation.

Parentah Operasi

Sateuacan nganggo munggaran:

Burn off any manufacturing residues by operating the grill on high for 15-20 minutes with the lid closed. Allow to cool completely before cleaning.

Nyaangan Pembakar Utama:

1. Pastikeun klep tabung gas dibuka sapinuhna.
2. Buka tutup grill.
3. Push and turn one main burner control knob to the TINGGI posisi.
4. Press the electronic igniter button (if available) or use a long match/lighter through the lighting hole.
5. Once lit, release the control knob.
6. If the burner does not light within 5 seconds, turn the knob to Pareum, wait 5 minutes for gas to dissipate, and repeat the process.
7. Repeat for other main burners as needed.
8. Adjust heat by turning the control knobs between RENDAH jeung TINGGI.

Nyaangan Burner Sisi:

1. Buka tutup burner samping.
2. Push and turn the side burner control knob to the TINGGI posisi.
3. Press the electronic igniter button or use a long match/lighter.
4. Once lit, release the control knob.
5. Adjust heat as required.

Gambar: Detil view of the side burner, ready for use with a pot or pan.

Shutting Down the Grill:

1. Turn all burner control knobs to the Pareum posisi.
2. Close the gas cylinder valve completely.
3. Allow the grill to cool down completely before cleaning or covering.

Pangropéa

beberesih sarta perawatan biasa bakal manjangkeun umur grill anjeun sarta mastikeun operasi aman.

Ngabersihkeun Parit Masak:

• After each use, while the grates are still warm, brush off food residue with a grill brush.
• For deeper cleaning, remove the grates once cooled and wash with warm soapy water. Rinse thoroughly and dry.

Cleaning Burner Covers and Burners:

• Periodically remove burner covers and clean off any accumulated grease or food particles.
• Inspect burner ports for blockages. Use a wire brush or paper clip to clear any debris.

Image: Close-up of the grill interior, showing the burner covers and the igniter mechanism, which require regular cleaning.

Manajemén gajih:

• Regularly check and empty the grease tray/cup located beneath the grill.
• Clean the grease tray with warm soapy water.

Image: The grease collection cup, designed to catch drippings, shown hanging below the grill body.

Bersihan Luar:

• Ngusap permukaan luar nganggo iklanamp lawon jeung detergent hampang.
• Hindarkeun pembersih abrasive anu tiasa ngaruksak bérés.

Panyimpenan:

• When not in use, store the grill in a dry, protected area.
• Disconnect the gas cylinder and store it outdoors in a well-ventilated area, away from direct sunlight and heat sources.
• Use a grill cover to protect the appliance from weather elements.

Image: The Activa Mastercook CALIFORNIA Gas Grill with its lid and cabinet doors closed, demonstrating its compact form for storage.

Pamérésan masalah

Upami anjeun mendakan masalah sareng grill anjeun, tingal masalah sareng solusi umum di handap ieu:

Upami masalah masih aya saatos nyobian solusi ieu, hubungi dukungan palanggan.

spésifikasi

Garansi sareng Rojongan

Information regarding specific warranty terms and conditions for the Activa Mastercook CALIFORNIA Gas Grill was not provided in the product data. Please refer to the documentation included with your purchase or contact Activa customer service directly for warranty details and support inquiries.

For spare parts availability, the provided information states "Information indisponible sur les pièces détachées". Please contact the manufacturer or your retailer for assistance with spare parts.
