Produk Leuwihview
The WAC Lighting Duo ACLED Dual Color Temperature Bar is a versatile under-cabinet lighting solution designed for various indoor applications. This fixture features an extruded solid aluminum body with a polycarbonate lens, providing diffused light to reduce glare. It offers dual color temperature options (2700K warm white and 3000K cool white) selectable via a three-way rocker switch. The unit is dimmable with compatible ELV or TRIAC dimmers and requires direct 120V AC wiring.
Gambar: Hareupeun view of the WAC Lighting Duo ACLED Dual Color Temperature Bar in white, showing the integrated rocker switch.
Émbaran Kasalametan
- PERHATOSAN: Résiko shock listrik. Pegatkeun sambungan kakuatan dina kotak sekering atawa circuit breaker saméméh instalasi atawa ngalayanan.
- Installation must be performed by a qualified electrician in accordance with national and local electrical codes.
- Ulah dipasangkeun caket sumber panas atanapi di tempat anu kalembabanna kaleuleuwihi.
- Pastikeun sadaya sambungan aman sareng insulated leres.
- produk ieu dimaksudkeun pikeun pamakéan indoor wungkul.
Eusi pakét
Pariksa yén sadaya komponén aya sateuacan ngamimitian pamasangan:
- Duo ACLED Dual Color Temperature Bar (1 unit)
- Pemasangan Hardware (screws, jangkar)
- Manual Pitunjuk (dokumén ieu)
spésifikasi
| Fitur | Rincian |
|---|---|
| Modél | BA-ACLED42-27/30 |
| Panjangna | 42 inci |
| Suhu Warna | 2700K (Bodas Haneut) / 3000K (Bodas Tiis) |
| Dipeunteun Jam | 54,000 jam |
| Dimming | Smooth and continuous to 10% with ELV or TRIAC dimmer |
| Voltage | 120V AC (Direct wiring, no transformer required) |
| Bahan | Extruded Solid Aluminum, Polycarbonate Lens |
| Warna | Bodas |
Image: Diagram showing various models of the Duo ACLED bar with corresponding lengths (8", 12", 18", 24", 30", 36", 42").
Image: Technical drawing illustrating the dimensions of the light bar, showing a length range of 8" to 42", a height of 2 3/4", and a depth of 1".
Parentah instalasi
- Nyiapkeun pikeun Instalasi: Ensure power is turned off at the circuit breaker before starting. Clear the installation area.
- Lokasi Pasang: Determine the desired mounting location under the cabinet. Mark the positions for mounting screws. The fixture has multiple knockouts for wiring flexibility.
- Ngamankeun fixture: Use the provided mounting hardware to securely attach the light bar to the underside of the cabinet. Ensure the fixture is level and stable.
- Wiring: Connect the 120V AC supply wires to the fixture's wiring. Follow standard electrical codes: connect live (black) to live, neutral (white) to neutral, and ground (green/bare copper) to ground. Use appropriate wire connectors. This fixture requires direct 120V AC wiring and does not need an external transformer or driver.
- Fungsi Uji: Once wiring is complete and secured, restore power at the circuit breaker. Test the light bar's operation and color temperature switch.
Parentah Operasi
Power On/Off and Color Temperature Selection
The Duo ACLED bar features a three-way rocker switch located on the fixture. This switch allows you to:
- Togél lampu On or Pareum.
- Pilih antara 2700K (Bodas haneut) pikeun ambiance cozy.
- Pilih antara 3000K (Bodas Tiis) for a brighter, more task-oriented light.
Fungsi Dimming
This fixture is designed for smooth and continuous dimming down to 10% of its maximum light output. To utilize the dimming feature, ensure you are using a compatible electronic low voltage (ELV) or TRIAC dimmer switch. Consult the dimmer's instructions for proper installation and operation.
Pangropéa
- beberesih: Disconnect power before cleaning. Use a soft, dry or slightly damp cloth to wipe the fixture. Avoid abrasive cleaners or solvents that may damage the finish or lens.
- umur panjang LED: Sumber lampu LED anu terintegrasi ieu gaduh umur anu dipeunteun 54,000 jam sareng henteu tiasa digentos ku pangguna.
Pamérésan masalah
| Masalah | Mungkin Cukang lantaranana | Solusi |
|---|---|---|
| Lampu henteu hurung. | Taya kakuatan, kabel leupas, switch faulty. | Check circuit breaker. Verify all wire connections are secure. Ensure the rocker switch is in the 'On' position. |
| Lampu kedip-kedip atanapi redup teu leres. | Incompatible dimmer, loose wiring, dimmer malfunction. | Ensure a compatible ELV or TRIAC dimmer is used. Check dimmer wiring. Consult a qualified electrician if issues persist. |
| Teu tiasa ngarobih suhu warna. | Rocker switch not fully engaged. | Ensure the three-way rocker switch is fully toggled to the desired color temperature setting. |
Minuhan sareng Sertifikasi
Star énergi Certified
Judul California 24 Patuh
Garansi sareng Rojongan
WAC Lighting products are manufactured to the highest standards and are backed by a manufacturer's warranty. For detailed warranty information, technical support, or to purchase accessories (such as joiner cables), please visit the official WAC Lighting websitus atanapi ngahubungan departemén layanan palanggan maranéhna.
Pencahayaan WAC Websitus: www.waclighting.com
