Bella Depot 36-inch Gold Retractable Ceiling Fan with Lights and Remote User Manual

1. Bubuka

Hatur nuhun pikeun meuliasing the Bella Depot 36-inch Gold Retractable Ceiling Fan with Lights and Remote. This manual provides important information for the safe installation, operation, and maintenance of your new ceiling fan. Please read this manual thoroughly before installation and keep it for future reference.

Émbaran Kasalametan

• Pastikeun kakuatan dipegatkeun dina breaker circuit saméméh instalasi atawa perawatan.
• Sadaya kabel kedah saluyu sareng kode listrik nasional sareng lokal.
• Taroskeun ka tukang listrik anu mumpuni upami anjeun henteu yakin ngeunaan prosedur kabel.
• Pasang kipas kana balok lalangit atanapi struktur pangrojong anu cocog anu sanggup nahan beurat kipas.
• Ulah ngabengkokkeun Panyekel sabeulah salila instalasi atawa beberesih.
• Jauhkeun barudak tina kipas nalika dioperasikeun.

2. Eusi Paket

Pariksa yén sadaya komponén aya sateuacan ngamimitian pamasangan:

• Perumahan motor kipas siling sareng Lampu LED Terpadu
• Retractable Blades (3)
• Downrod (pilihan 5 inci sareng 10 inci)
• Kanopi
• Ningkatna Kurung
• Kadali jauh
• Paket Hardware (screws, mur kawat, jsb.)
• Instruksi Manual

Gambar: Ngabeledug view of the Bella Depot 36-inch retractable ceiling fan showing various components like the motor housing, blades, downrods, and canopy.

3. Spésifikasi

Image: Detailed diagram illustrating the dimensions of the 36-inch ceiling fan, including the canopy, downrods, and overall height and width.

4. Parentah instalasi

Sateuacan Anjeun Ngawitan: Ensure the power supply is turned off at the circuit breaker. Read all instructions carefully before proceeding.

Alat anu diperyogikeun:

• Obeng Phillips
• Obeng flathead
• rengkuh adjustable
• Striper kawat
• Pita listrik
• Tangga

Léngkah-léngkah pamasangan:

1. Pamasangan bracket dipasang: Secure the mounting bracket to the ceiling outlet box. Ensure the outlet box is securely fastened to a building structure (e.g., a ceiling joist) and can support the fan's weight.
2. Majelis Downrod: Choose the desired downrod (5-inch or 10-inch). Feed the fan wires through the downrod. Insert the downrod into the fan motor housing and secure it with the provided pin and screw.
3. Gantung kipas: Angkat rakitan kipas kalayan ati-ati teras gantungkeun dina kait braket pemasangan. Ieu bakal ngabébaskeun leungeun anjeun pikeun masang kabel.
4. Sambungan Wiring: Connect the fan's electrical wires to the household supply wires according to local electrical codes. Typically, this involves connecting:
   • Green/Ground wire from fan to bare copper/ground wire from house.
   • White/Neutral wire from fan to white/neutral wire from house.
   • Black/Live wire from fan to black/live wire from house.
   Anggo mur kawat anu disayogikeun sareng amankeun sambunganna nganggo pita listrik.
5. Pamasangan Kanopi: Slide the canopy up to the ceiling and secure it to the mounting bracket with the screws. Ensure all wires are tucked neatly inside the canopy.
6. Lampiran sabeulah: The blades are retractable and integrated into the fan housing. No separate blade attachment is required.
7. Pamasangan Kit Lampu: The LED light is integrated. Ensure all connections are secure.

Note: Professional installation is recommended if you are not familiar with electrical wiring.

5. Operasi

Your Bella Depot ceiling fan is operated via the included remote control. Ensure a 23A 12V battery is installed in the remote (battery not included).

Fungsi Remote Control:

• Kipas ON/OFF: Ngahurungkeun atanapi mareuman kipas.
• Kontrol Laju Kipas: Adjusts between 6 fan speeds.
• Lampu ON/OFF: Hurungkeun atawa mareuman lampu LED.
• Robah Suhu Warna: Cycles through 3 color temperatures (Warm Light, Warm White, White Light). Each time the light is turned on, it may cycle to the next color temperature.
• Penyesuaian Caang: Dims or brightens the LED light.
• Fungsi Timer: Sets the fan to turn off after 1, 2, 4, or 8 hours.
• Fungsi Maju / Mundur: Ngarobah arah rotasi sabeulah.

Image: Illustration demonstrating the three available light color temperatures: Warm Light, Warm White, and White Light, as controlled by the remote.

Fungsi Maju sareng Mundur:

The fan features a forward and reverse function to optimize air circulation for different seasons:

• Forward (Summer Mode): Bilahna muter ka arah sabalikna jarum jam, ngadorong hawa ka handap pikeun nyiptakeun angin anu niiskeun.
• Reverse (Winter Mode): Bilahna muter searah jarum jam, narik hawa ka luhur pikeun ngiderkeun hawa haneut anu kajebak di deukeut lalangit.

Image: Diagram showing the fan's forward mode for summer (airflow down) and reverse mode for winter (airflow up), optimizing room temperature.

6. Pangropéa

Pangropéa rutin ngajamin kinerja optimal sareng umur panjang kipas siling anjeun.

• beberesih: Bersihkeun kipas sacara berkala nganggo lap anu lemesamp lawon. Ulah nganggo pembersih atanapi pangleyur anu abrasif, sabab éta tiasa ngaruksak lapisan atanapi bilahna. Pastikeun daya pareum sateuacan dibersihkeun.
• Inspeksi sabeulah: Check the retractable blades for any dust accumulation. Clean gently if necessary.
• Kateguhan Sekrup: Periodically check all screws for tightness. Due to natural movement, some connections may become loose over time.
• Sumber cahaya: The LED light is integrated and designed for long life. If replacement is needed, contact customer support.

7. Cara ngungkulan

Sateuacan ngahubungan layanan palanggan, mangga tingal pituduh ngungkulan ieu:

8. Garansi sarta Rojongan Palanggan

Kipas langit-langit Bella Depot ieu dilengkepan ku garansi 1 taun ti tanggal dibeuli, ngawengku defects manufaktur. Punten tahan bukti pameseran anjeun pikeun klaim garansi.

For technical assistance, troubleshooting beyond this manual, or warranty inquiries, please contact Bella Depot customer service:

• Pabrikan: Bella Depot
• Penjual: Bella Depot (on Amazon)
• Refer to your purchase platform for direct contact information or visit the official Bella Depot store.

Note: The remote control requires a 23A 12V battery, which is not included and not covered under warranty.
