Morpilot 4-in-1 Electric Milk Frother HS007 User Manual

Bubuka

This manual provides essential instructions for the safe and efficient operation of your Morpilot 4-in-1 Electric Milk Frother. Please read this manual thoroughly before first use and retain it for future reference.

Parentah Kasalametan penting

Nalika nganggo alat listrik, pancegahan kaamanan dasar kedah diturutan pikeun ngirangan résiko kahuruan, kejutan listrik, sareng tatu pikeun jalma, kalebet ieu:

• Baca sagala parentah.
• Ulah noél surfaces panas. Paké handles atanapi knobs.
• Pikeun ngajaga tina shock listrik, ulah beuleum kabel, colokan, atawa alat dina cai atawa cairan séjén.
• Pengawasan anu ketat diperyogikeun nalika alat naon waé dianggo ku atanapi caket barudak.
• Cabut colokan tina stop kontak nalika henteu dianggo sareng sateuacan beberesih. Ngidinan pikeun niiskeun sateuacan dipasang atanapi nyabut bagian, sareng sateuacan ngabersihkeun alat.
• Entong ngoperasikeun alat naon waé nganggo kabel atanapi colokan anu rusak atanapi saatos alatna teu tiasa dianggo, atanapi parantos ruksak dina cara naon waé. Balikkeun alat ka fasilitas layanan otorisasi anu pangcaketna pikeun pamariksaan, perbaikan, atanapi pangaturan.
• Pamakéan kantétan aksésori anu henteu disarankeun ku produsén alat tiasa nyababkeun kahuruan, kejutan listrik, atanapi cilaka jalma.
• Ulah make di luar.
• Entong ngantepkeun kabel ngagantung dina ujung méja atanapi konter, atanapi nyabak permukaan anu panas.
• Ulah nempatkeun dina atawa deukeut gas panas atawa burner listrik, atawa dina oven dipanaskeun.
• Sok pasangkeun heula colokan kana alat, teras colokkeun kabel kana stop kontak témbok. Pikeun megatkeun sambungan, balikkeun sagala kadali kana "off", teras cabut colokan tina stop kontak témbok.
• Ulah make alat pikeun lian ti pamakéan dimaksudkeun.
• Perkakas ieu kanggo panggunaan rumah tangga wungkul.
• Awas: The frother cup is not dishwasher safe.

Eusi pakét

Pastikeun yén sadaya barang aya nalika ngabongkar:

• 1 x Morpilot Electric Milk Frother
• 1 x Base kakuatan
• 1 x Foam Whisk
• 1 x Pemanasan Whisk
• 1 x Sikat Pembersih
• 1 x Manual Pamaké

Komponén produk

Familiarize yourself with the parts of your milk frother:

Gambar 1: The Morpilot HS007 Electric Milk Frother, showing its main body, transparent lid, handle, power button, and mode indicators (Red, Blue, Purple, Green).

The frother consists of a main unit with a transparent cup, a handle, and a control panel on the base. The transparent cup allows for visual monitoring of the frothing process. The control panel features a central power button and four indicator lights for different functions.

Disetél

1. Buka bungkus sadaya komponén sareng cabut bahan bungkusan.
2. Tempatkeun dasar daya dina permukaan anu stabil, rata, sareng garing.
3. Ensure the frother cup is clean and dry before first use. Refer to the "Cleaning and Maintenance" section for initial cleaning instructions.
4. Insert the desired whisk (foam whisk for frothing, heating whisk for heating only) onto the shaft at the bottom of the frother cup.
5. Connect the power base to a suitable electrical outlet.

Parentah Operasi

The Morpilot HS007 offers four distinct functions, each activated by a single button press and indicated by a specific color.

Gambar 2: Diagram illustrating the four operating modes of the Morpilot milk frother: Hot dense milk foam, Cold milk foam, Hot milk, and Hot airy milk foam, each with an example beverage.

Gambar 3: Visual representation of the four functions: Hot dense foam (Red), Cold foam (Blue), Hot milk/cocoa (Purple), and Hot airy foam (Green), showing the corresponding button presses.

Pedoman Kapasitas

Gambar 4: Close-up of the frother's visual glass, showing the "MAX 250ML" mark for milk frothing and "MIN 130ML" for minimum liquid level.

Observe the graduated markings inside the frother cup to prevent overflow:

• Maximum Heating Capacity: 600 ml (for heating milk without frothing).
• Maximum Frothing Capacity: 250 ml (for creating milk foam).
• Minimum Heating/Frothing Capacity: 130 ml.

Always ensure the milk level is between the MIN and MAX indicators for optimal performance and to avoid spillage.

Pamilihan Fungsi

1. Prepare the Frother: Ensure the frother cup is clean and the correct whisk is installed.
2. Tambahkeun Susu: Pour the desired amount of milk into the frother cup, adhering to the capacity guidelines.
3. Pilih Fungsi: Press the power button on the base to cycle through the functions. Each press will illuminate a different color indicator:
• Lampu Beureum: Hot Dense Milk Foam (Press once)
• Cahaya Biru: Cold Milk Foam (Press twice)
• Cahaya Ungu: Hot Milk or Hot Cocoa Powder (Press three times)
• Lampu héjo: Hot Airy Milk Foam (Press four times)
4. Mimitian Operasi: The frother will begin operation automatically after selecting the function.
5. Pareuman otomatis: The appliance will automatically stop once the selected process is complete.
6. tuang: The frother features a specially designed anti-drip spout for controlled pouring, ideal for latte art.


   Gambar 5: The Morpilot milk frother pouring frothed milk into a cup, demonstrating its precision spout for creating latte art.

beberesih sarta Pangropéa

Regular cleaning ensures optimal performance and extends the lifespan of your Morpilot Milk Frother.

Gambar 6: The Morpilot milk frother being rinsed under a kitchen faucet, highlighting its ease of cleaning. A cleaning brush is included for thorough cleaning.

1. Cabut colokan: Salawasna cabut alat ti toko listrik sateuacan diberesihan.
2. Tenang: Allow the frother to cool completely before handling.
3. Leupaskeun Whisk: Carefully remove the whisk from the frother cup.
4. Clean Frother Cup: Wash the interior of the frother cup with warm, soapy water using the provided cleaning brush. Rinse thoroughly.
5. Awas: The frother cup is TEU Aman pikeun mesin cuci piring. Nyeuseuh ku leungeun wungkul.
6. Kocok Bersih: Wash the whisk with warm, soapy water and rinse.
7. Ngusap Luar: Lap bagian luar frother sareng power base ku adamp lawon. Ulah ngalelepkeun dasar daya kana cai.
8. garing: Pastikeun sadaya bagian tos rengse garing sateuacan reassembling atanapi nyimpen.

Pamérésan masalah

If you encounter issues with your Morpilot Milk Frother, refer to the following common problems and solutions:

spésifikasi

• merek: Morpilot
• Jumlah modél: HS007
• warna: Hideung
• kakuatan: 550 Watt
• Maximum Heating Capacity: 600 mililiter
• Maximum Frothing Capacity: 250 mililiter
• Tingkat Cairan Minimum: 130 mililiter
• Bahan: palastik
• Fitur husus: Automatic Shut-off, Latte Design Spout, 4-in-1 Function, Visual Glass
• Beurat barang: 1.03 kg
• Ukuran Paket: 23.4 x 15.8 x 15.5 cm
• Sumber Daya: Kabel Listrik
• Parentah perawatan: Hand wash only (Not dishwasher safe)

Garansi sareng Rojongan

For warranty information or technical support, please refer to the contact details provided with your purchase documentation or visit the official Morpilot websitus.
