Buku Panduan Pangguna Pembentuk Susu Induksi YASHE SB-0902-2

1. Bubuka

Thank you for choosing the YASHE SB-0902-2 Induction Milk Frother. This manual provides essential information for the safe and efficient operation, maintenance, and troubleshooting of your new appliance. Please read these instructions carefully before first use and retain them for future reference.

The YASHE SB-0902-2 is designed to quickly and easily prepare various milk-based beverages, including frothed milk for cappuccinos and lattes, heated milk, and hot chocolate. Its induction heating technology ensures consistent results, and the detachable, dishwasher-safe jug simplifies cleaning.

Image 1: YASHE SB-0902-2 Induction Milk Frother. This image shows the complete milk frother unit, including the base and the jug, alongside a cup of frothed coffee, illustrating its primary function.

2. Parentah Kasalametan

To prevent damage or injury, always observe the following safety precautions:

• Baca sadaya pitunjuk sateuacan ngaoperasikeun alat.
• Do not immerse the power base, cord, or plug in water or other liquids. The jug is detachable and washable, but the base unit is not.
• Pastikeun voltage dituduhkeun dina alat cocog vol mains lokal Anjeuntage saméméh nyambungkeun.
• Do not operate the appliance with a damaged cord or plug, or if it malfunctions or has been damaged in any way. Contact customer support for assistance.
• Jauhkeun alat tina jangkauan barudak. Pengawasan anu ketat diperyogikeun nalika alatna dianggo caket barudak.
• Hindarkeun kontak sareng bagian anu gerak.
• Do not touch hot surfaces. The jug and its contents will become hot during operation. Use the handle.
• Always place the appliance on a stable, level, heat-resistant surface.
• Cabut colokan tina stop kontak nalika henteu dianggo sareng sateuacan beberesih. Ngidinan pikeun niiskeun sateuacan dipasang atanapi nyabut bagian, sareng sateuacan ngabersihkeun alat.
• This appliance is equipped with an automatic shut-off feature for safety and energy saving.
• Paké ngan kantétan dianjurkeun atawa dijual ku produsén.

Image 2: Safe Operation. This graphic highlights key safety features of the frother, including automatic shut-off, temperature control, and quiet operation, ensuring user safety and convenience.

3. Produk Langkungview

3.1 Komponén

• Milk Frother Jug (with handle and whisk)
• Base kakuatan
• Udung
• Kabel Daya
• Manual pangguna (dokumén ieu)

3.2 Fitur

• Fungsi 4-in-1: Capable of producing cold milk foam, heated milk, hot milk foam, and hot chocolate.
• Operasi Hiji-Klik: Simple and intuitive control with a single button.
• Detachable & Dishwasher-Safe Jug: Stainless steel jug (304 grade) is removable and safe for dishwasher cleaning.
• Pareuman otomatis: Enhances safety and conserves energy by turning off after operation.
• Operasi sepi: Designed to function silently, minimizing disturbance.
• Induction Heating: Efficient and consistent heating.
• Tutup transparan: Allows monitoring of the frothing process.
• Cool-Touch Housing: The exterior remains cool during operation.
• Variable Foam Setting: Adjusts foam consistency.

3.3 Spésifikasi

4. Setélan

1. Ngabongkar: Sacara saksama miceun sadaya komponén tina bungkusan. Simpen bungkusan pikeun neundeun atanapi transportasi ka hareup.
2. Bersihan awal: Before first use, wash the milk frother jug and lid with warm soapy water, then rinse thoroughly and dry. Wipe the power base with a damp lawon. Ulah ngalelepkeun dasar daya kana cai.
3. panempatan: Place the power base on a dry, stable, and level surface, away from heat sources and water.
4. Sambungkeun Kakuatan: Colokkeun kabel listrik kana stop kontak listrik anu cocog (220V).

5. Parentah Operasi

The YASHE SB-0902-2 features a simple one-button operation for various milk preparations.

Image 3: One-key Easy Operation. This image illustrates the frother's versatility, showing it can produce cold milk foam, heated milk, hot chocolate, and hot milk foam with a single button press.

5.1 Filling the Jug

• Ensure the whisk is correctly inserted at the bottom of the jug.
• Pour milk into the jug. Observe the internal MAX/MIN markings.
• Pikeun heating milk or making hot chocolate, do not exceed the MAX (230ml / 7.78 oz) garis.
• Pikeun frothing milk (hot or cold), do not exceed the MAX (130ml / 4.4 oz) line to prevent overflow due to foam expansion.
• For best results, use whole milk, soy milk, or almond milk with a fat content of 3% or higher.

Image 4: Precise Tick Marks. This image clearly displays the internal MAX and MIN fill lines within the frother jug, indicating the maximum capacities for heating milk (230ml) and frothing milk (130ml).

5.2 Modeu Operasi

Place the filled jug onto the power base and secure the lid. Press the power button to select your desired mode:

• Hot Milk Froth: Press the button once. The indicator light will illuminate red. The frother will heat and froth the milk to create dense, creamy foam for cappuccinos and lattes.
• Buih Susu Tiis: Press and hold the button for approximately 2 seconds. The indicator light will illuminate blue. The frother will froth the milk without heating, ideal for iced coffees or cold beverages.
• Hot Milk (no froth): Remove the whisk from the jug. Press the button once. The indicator light will illuminate red. The frother will heat the milk without frothing.
• Coklat panas: Add milk and chocolate powder/syrup to the jug (ensure it does not exceed the 230ml MAX line). Press the button once. The indicator light will illuminate red. The frother will heat and mix the ingredients.

The appliance will automatically shut off once the selected program is complete. Carefully remove the jug by its handle and pour the prepared milk.

Image 5: Dense and Creamy Froth. This image shows the frother pouring rich, dense milk foam into a glass, demonstrating the quality of froth it produces for beverages like lattes or cappuccinos.

6. beberesih sarta Pangropéa

Regular cleaning ensures optimal performance and extends the lifespan of your milk frother.

6.1 Cleaning the Jug and Lid

• Sanggeus unggal pamakéan, cabut colokan alat jeung ngidinan pikeun niiskeun handap.
• Leupaskeun kendi tina dasar kakuatan.
• The stainless steel jug and lid are dishwasher-safe. Alternatively, they can be washed by hand with warm soapy water and a non-abrasive sponge. Rinse thoroughly and dry immediately.
• Ensure the whisk is clean and free of milk residue.

6.2 Ngabersihan Dasar Daya

• Lap bagian luar dasar daya ku kaén anu lemes,amp lawon.
• Do not use abrasive cleaners or scourers, as these can damage the surface.
• Ulah pernah neuleumkeun dasar kakuatan dina cai atawa cairan séjén.

Image 6: Easy to Clean. This image demonstrates the ease of cleaning the frother, showing the jug being rinsed under a tap and placed in a dishwasher, highlighting its detachable and dishwasher-safe design.

7. Cara ngungkulan

If you encounter any issues with your YASHE Milk Frother, please refer to the following table before contacting customer support.

8. Garansi jeung Rojongan

For warranty information and customer support, please refer to the documentation included with your purchase or contact YASHE customer service directly. Keep your proof of purchase for warranty claims.
