FOTILE SD2F-P5 3-in-1 In-Sink Dishwasher & Kitchen Sink Combo User Manual

1. Produk Langkungview

The FOTILE SD2F-P5 is an innovative 3-in-1 appliance that seamlessly integrates a kitchen sink, a powerful dishwasher, and a dedicated produce cleaner into a single, space-saving unit. Designed for modern homes, especially those with limited kitchen space, it offers a hygienic and efficient solution for daily dishwashing and food preparation needs.

Fitur konci:

• Revolutionary 3-in-1 Design: Combines kitchen sink, dishwasher, and produce wash for optimized efficiency and hygiene.
• 360 ° beberesih: Equipped with a rotary spray arm and pasteurization mode for effective dirt removal and 99.99% residue elimination.
• Modeu beberesih customizable: Offers Eco, Delicate, Normal, and Intensive modes for various dishwashing needs.
• Efficient Energy and Water Conservation: Low annual energy consumption (159 kWh) and minimal water usage (3 gallons per cycle).
• Sanitizing Pasteurization Process: Heats water up to 158°F for sanitized dishes and includes convection drying.
• Konci Kaamanan Anak: Prevents accidental opening during operation.
• Ergonomic Top Mount Design: Maximizes kitchen space and minimizes bending for loading/unloading.
• Konstruksi awét: Crafted with tempered glass and stainless steel for long-lasting performance.

Figure 1: The FOTILE SD2F-P5 In-Sink Dishwasher and Kitchen Sink Combo.

Gambar 2: Interior view highlighting the all-in-one design for washing and drying.

2. Setup jeung Instalasi

For detailed installation instructions, please refer to the official Installation Manual PDF provided with your product or download it from the manufacturer's websitus. Pamasangan profésional disarankeun.

Unduh Manual Instalasi: Manual Instalasi (PDF)

Naon anu aya dina Kotak:

• In-Sink Dishwasher Unit
• 1 * Dishwasher Basket
• 1 * Produce Basket
• Basic Plumbing Spare Parts
• Manual pamaké
• Kartu Garansi

angka 3: dimensi produk pikeun tata instalasi.

3. Parentah Operasi

Panél kontrol:

The FOTILE SD2F-P5 features a sleek touch control console integrated into the tempered glass surface. Simply touch the icons to select desired functions and cycles. The digital display shows remaining time or selected mode.

Figure 4: The intuitive touch control panel.

Dishwashing Modes:

The dishwasher offers four versatile cleaning modes to suit different levels of soiling and item fragility. The unit self-heats water to the optimal temperature for each cycle.

• Delicate Mode: Ideal for lightly soiled or fragile items. Washes at 140°F for 15 minutes.
• Modeu Normal: For moderately soiled items. Washes at 140°F for 60 minutes.
• Mode Intensif: For heavily soiled pots and pans. Washes at 167°F for 80 minutes.
• Modeu Eco: Energy and water-saving mode for moderately to heavily soiled items. Washes at 126°F for 180 minutes.

Gambar 5: Leuwihview of dishwashing modes and their characteristics.

Figure 6: Delicate Mode for quick and fragile item washing.

Figure 7: Intensive Mode for heavy-duty dish cleaning.

Produce Washing:

The integrated produce wash feature uses HydroJet technology with water pulses and spray rinse to effectively remove pesticide residues from fruits and vegetables. It can also remove dirt and soil from raw seafood.

• Delicate Mode: 7 menit.
• Modeu Normal: 12 menit.
• Mode Intensif: 15 menit.

Figure 8: Advanced produce washing for fruits and vegetables.

Figure 9: Delicate Mode for produce washing.

Figure 10: Human-centered design elements including flat top mount, enhanced safety, memory wash, and top load design.

4. Pangropéa

Ngabersihan Unit:

To maintain the pristine condition and optimal performance of your FOTILE SD2F-P5, regular cleaning is essential. The tempered glass and stainless steel surfaces are designed for easy maintenance.

• Pitunjuk Perawatan Produk: Ngusap nganggo iklanamp cloth. Avoid abrasive cleaners that may scratch the surfaces.
• Saringan beberesih: The unit features an easily removable filter at the bottom of the dishwasher basin. Regularly lift out and clean the filter to prevent clogs and ensure efficient operation.
• High-Temperature Sanitization: The pasteurization mode heats water to 167°F, providing a 99% sterilization rate for exceptional cleanliness.
• Hassle-Free Drying: The triple drying system, including PTC hot wind drying, prevents secondary contamination and ensures dishes are dry.

Figure 11: High-temperature sanitization for thorough cleaning.

Figure 12: The triple drying system ensures dishes are ready to use.

Panyimpenan Henteu Bau:

The unit features automatic air circulation that keeps dishes clean and odor-free for up to 96 hours, even when you're on the go. This ensures your dishes are always fresh and ready for use.

Figure 13: Odor-free storage feature for prolonged freshness.

5. Cara ngungkulan

If you encounter any issues with your FOTILE SD2F-P5, please refer to the troubleshooting section in the comprehensive User Manual (PDF) for common problems and solutions. For persistent issues or technical support, please contact FOTILE customer service.

Unduh Manual Pamaké: Manual Pamaké (PDF)

6. Spésifikasi produk

Figure 14: Energy and water efficiency comparison.

7. Garansi jeung Rojongan

Your FOTILE SD2F-P5 comes with a comprehensive warranty. Please refer to the Warranty Card included in your product packaging for specific terms and conditions. FOTILE is committed to providing excellent customer service.

Rojongan Palanggan:

• Garanti Industri-Anjog
• 2,400 Nationwide Service Centers
• Worry-Free Installation Service Referral
• Customer Service Support 7 Days a Week

For further assistance, visit the official FOTILE Brand Store:

Visit the FOTILE Store on Amazon
