Bubuka
This manual provides essential information for the safe and efficient operation, installation, and maintenance of your Daikin 4-Zone Mini Split Air Conditioner Heat Pump system. The Daikin 4MXM-A Series R32 pre-charged outdoor condenser powers four independently controlled FTXV Series wall-mounted indoor fan coils, offering advanced climate control and energy efficiency. This Wi-Fi-enabled system integrates with the Daikin One Home app for convenient remote management.
Setup sareng Instalasi
Pamasangan profésional diperlukeun: For optimal performance and to ensure warranty validity, this Daikin Mini Split system must be installed by an HVAC-certified technician. Improper installation can lead to system malfunction, safety hazards, and void the manufacturer's warranty.
Komponén Kaasup:
- 1 x 4MXM36AVJU9 Multi-Split 36,000 BTU Heat Pump Air Conditioner Outdoor Condenser
- 4 x FTXV Series Indoor Fan Coils with Remote Controls
- 4 x Maxwell 15 ft Pre-Flared Installation Kits with Interconnecting Cables
- 1 x Maxwell Wall Mounting Bracket for Outdoor Unit
Penempatan Unit Luar:
Ensure the outdoor unit is placed on a stable, level surface or mounted securely using the provided bracket. Maintain adequate clearance around the unit for proper airflow and maintenance access.
This image provides a visual representation of the Daikin 4-Zone system, showing the dimensions of both the outdoor condenser unit and the indoor FTXV fan coil units. It also includes a detailed specification table for the system, outlining energy efficiency ratings, power supply, operational ranges, sound pressure levels, refrigerant type, and piping details.
The outdoor condenser unit features a durable design, including a Blue Fin Anti-Corrosion Treatment on the heat exchanger, which enhances its longevity and performance in various environmental conditions.
Parentah Operasi
Modeu Kontrol:
The system offers multiple operating modes for personalized comfort:
- Otomatis: Automatically selects heating or cooling based on the set temperature.
- keren: Provides cooling to lower room temperature.
- garing: Ngurangan kalembaban di rohangan.
- Panas: Provides heating to raise room temperature.
- Ngan kipas: Sirkulasi hawa tanpa pemanasan atawa cooling.
Fitur pinter:
- Konektipitas Wi-Fi: Connect your system to your home Wi-Fi network.
- Daikin One Home App: Control and monitor your system remotely using the Daikin One Home app on your smartphone or tablet.
- Kontrol sora: Cocog sareng Alexa sareng Google Home pikeun paréntah sora anu merenah.
- Aliran hawa anu tiasa diatur: Utilize dual airflow and adjustable flaps/louvers to direct air for optimal comfort.
- ECONO Operation: An energy-saving mode that minimizes power consumption.
- Modeu Operasi anu Kuat: Delivers quick temperature adjustments for fast comfort.
- Operasi sepi: Designed for minimal noise output.
- LED Self-Diagnostics: Provides error codes or indicators for easy troubleshooting.
This diagram illustrates the key components of the FTXV Series indoor unit, including the air inlet, air outlet, adjustable flaps and louvers, and the control display. It also highlights the location of the 2-washable air filters and 2-Titanium Apatite deodorizing filters, essential for air quality and maintenance. The display shows indicators for ON/OFF, indoor temperature/humidity, Wireless LAN, Timer, and Operation.
Pangropéa
Regular maintenance ensures the longevity and efficiency of your Daikin system. Always turn off the power supply to the unit before performing any maintenance.
Saringan beberesih:
The indoor units are equipped with 2-Washable Air Filters jeung 2-Titanium Apatite Deodorizing Filters. These should be cleaned regularly (e.g., every two weeks or as needed) to maintain air quality and system performance. Refer to the indoor unit diagram in the Operating Instructions section for filter locations.
- Gently nyabut saringan.
- Wash washable filters with lukewarm water and mild detergent. Rinse thoroughly and allow to air dry completely before reinserting.
- Titanium Apatite Deodorizing Filters can be cleaned by vacuuming or rinsing with water. Replace these filters periodically as recommended by Daikin.
Perawatan Unit Luar:
The outdoor condenser unit features a Blue Fin Anti-Corrosion Treatment on its heat exchanger, designed for enhanced durability. Keep the area around the outdoor unit clear of debris, leaves, and other obstructions to ensure proper airflow.
Palayanan profésional:
It is recommended to have your system inspected and serviced by a qualified HVAC technician annually to ensure optimal performance and address any potential issues.
Pamérésan masalah
Sateuacan ngahubungan jasa, mangga parios masalah umum ieu:
| Masalah | Mungkin Cukang lantaranana | Solusi |
|---|---|---|
| Unit teu hurung | No power supply, remote control batteries low, circuit breaker tripped. | Check power connection, replace remote batteries, reset circuit breaker. |
| Cooling / pemanasan teu cukup | Dirty air filters, blocked outdoor unit, incorrect mode setting, temperature setting too high/low. | Clean air filters, clear obstructions from outdoor unit, select appropriate mode, adjust temperature. |
| Sora teu biasa | Bagian anu leupas, barang asing, sora operasi normal (contona, aliran refrigeran). | Inspect for loose parts, remove foreign objects. If noise persists or is abnormal, contact service. |
| Bocoran cai tina unit jero ruangan | Selang solokan mampet, pamasanganna teu bener. | Check and clear drain hose. For persistent leaks or installation issues, contact a professional. |
If the problem persists after attempting these solutions, or if an error code is displayed, please contact a qualified HVAC technician for assistance.
spésifikasi
| Fitur | Rincian |
|---|---|
| merek | DAIKIN |
| Info modél | 4MXM36AVJU9 (Outdoor Unit) + FTXV09/09/09/12 (Indoor Units) |
| Kamampuh cooling | 34,200 BTU (12,500 BTU Min – 37,000 BTU Maks) |
| Kapasitas pemanasan | 34,600 BTU (9,900 BTU Min – 43,000 BTU Maks) |
| Peunteun SEER2 | 20 |
| Rating HSPF2 | 9.5 |
| Rating EER2 | 10 |
| COP | 1.8 |
| Tipe Refrigerant | Urang Sunda-32 |
| Sasayogian tanaga | 1Ph, 60 Hz, 208-230V |
| Rentang Operasi (Pendinginan) | 14°F nepi ka 115°F |
| Rentang Operasi (Pemanasan) | 5°F nepi ka 59.9°F |
| Tingkat Noise (Luar Ruangan) | 56 dB(A) |
| Tingkat Noise (Dalam Ruangan) | 22 dB(A) |
| Diménsi Unit Luar Ruangan (P x L x T) | 1 x 1 x 1 inci (Diménsi Produk) |
| Beurat Unit Luar | 140 pon |
| Max Floor Area Coverage | 1750 suku pasagi |
| Fitur husus | 3D Airflow, Auto-Changeover, Automatic Defrosting, Dry Program, Intelligent Eye, Quick Warming Function, Quiet Operation |
Émbaran jaminan
This Daikin Mini Split system includes a 12-taun jaminan pabrik. To ensure the validity of this warranty, the system must be installed by an HVAC-certified technician. Please retain your proof of purchase and installation records for warranty claims.
Rojongan Palanggan
For technical assistance, troubleshooting beyond this manual, or warranty inquiries, please contact Daikin customer support or your certified HVAC installer. You can find contact information on the official Daikin websitus atawa dina dokuméntasi disadiakeun kalawan produk Anjeun.
