1. Bubuka
This user manual provides comprehensive instructions for the Huidun Mini PC, Model H30 N150. This compact and powerful mini PC is equipped with the Intel Twin Lake N150 processor, 16GB DDR4 RAM, and a 512GB M.2 SSD, designed for efficient daily work, office tasks, and home entertainment. It supports 4K dual display output, features 5G WiFi and Bluetooth connectivity, and comes with Windows 11 Pro pre-installed. Please read this manual thoroughly before operating your device to ensure optimal performance and longevity.
Gambar: Hareupeun view of the Huidun Mini PC H30 N150, showcasing its compact design and Intel Inside branding.
2. Naon dina Box
Saatos muka bungkusan, mangga pariksa yén sadaya komponén aya:
- 1 x Huidun Mini PC H30
- 1 x adaptor kakuatan
- 1 x Kabel HDMI
- 1 x Manual Pamaké (dokumén ieu)
- 1 x VESA Gunung kalawan screws
3. Setup Guide
3.1 Nyambungkeun Mini PC Anjeun
- Sambungan Daya: Connect the power adapter to the DC-in port on the mini PC and then plug it into a power outlet.
- Sambungan tampilan: Connect your monitor(s) to the HDMI ports on the mini PC using the provided HDMI cable. The mini PC supports dual 4K displays.
- Sambungan Periferal: Connect your keyboard, mouse, and other USB devices to the available USB 2.0 or USB 3.0 ports.
- Sambungan jaringan: For wired internet, connect an Ethernet cable to the RJ45 LAN port. For wireless internet, the mini PC supports 5G WiFi.
- Sambungan Audio: Connect speakers or headphones to the 3.5mm audio jack if desired.
Gambar: Detil view of the Huidun Mini PC's versatile ports, including USB, HDMI, LAN, and audio jack.
3.2 Mimiti Boot-up
After connecting all necessary peripherals, press the power button located on the front of the mini PC. The system will boot into Windows 11 Pro. Follow the on-screen instructions to complete the initial Windows setup, including language, region, and network settings.
Image: The Huidun Mini PC connected to dual monitors, displaying the Windows 11 Pro interface, highlighting its pre-installed operating system.
3.3 Pamasangan Dudukan VESA
The included VESA bracket allows you to mount the mini PC to the back of a compatible monitor or to a wall, saving desk space. Secure the VESA bracket to the mini PC using the provided screws, then attach the bracket to your monitor's VESA mounting holes or a wall mount.
4. Parentah Operasi
4.1 Pamakéan Umum
The Huidun Mini PC is designed for a wide range of applications, from everyday computing and office tasks to educational and entertainment purposes. Its Intel Twin Lake N150 processor ensures smooth performance for multitasking, web browsing, document editing, and media consumption.
Image: A desktop setup showing the Huidun Mini PC facilitating multiple open applications on a single monitor, demonstrating its multitasking capabilities.
4.2 Setélan tampilan ganda
Utilize the two HDMI ports to connect two monitors simultaneously. This feature enhances productivity by allowing for extended desktop space or mirrored displays. To configure dual displays in Windows 11, right-click on the desktop, select "Display settings," and adjust the display arrangement and resolution as needed.
Image: The Huidun Mini PC connected to two 4K monitors, illustrating its dual display capability for enhanced productivity and visual clarity.
4.3 Ékspansi gudang
The mini PC comes with a 512GB M.2 SSD. For additional storage, it supports an expandable 2.5" SATA HDD/SSD up to 2TB. To install an additional drive, refer to the detailed instructions in the "Maintenance" section or consult the online support resources.
Gambar: Hiji ngabeledug view of the Huidun Mini PC showing the compartment for an additional 2.5" SATA HDD/SSD, demonstrating its storage expansion capability.
4.4 Konéktipitas
The mini PC offers robust connectivity options:
- Wifi: Supports dual-band 5G WiFi for fast and stable wireless internet.
- Bluetooth 4.2: Connect wireless peripherals such as keyboards, mice, and headphones.
- RJ45 Gigabit Ethernet: Provides a reliable wired network connection for high-speed data transfer.
5. Pangropéa
5.1 beberesih
To maintain optimal performance, regularly clean the exterior of the mini PC with a soft, dry cloth. Ensure the ventilation grilles are free from dust and debris to prevent overheating. Do not use liquid cleaners or aerosols directly on the device.
5.2 Apdet parangkat lunak
Keep your Windows 11 Pro operating system and drivers updated to ensure security, stability, and optimal performance. Windows updates can be managed through the "Settings" app under "Windows Update."
5.3 Sistem Pendinginan anu Éfisién
The Huidun Mini PC features an optimized cooling solution with a copper tube, aluminum heat sink, and a fan operating at 4,500 RPM. This system is designed to dissipate heat quickly, ensuring stable operation and extending the CPU's lifespan. Avoid blocking the ventilation openings to allow for proper airflow.
Gambar: Hiji internal view of the Huidun Mini PC highlighting its efficient cooling system components, including the copper tube, aluminum heat sink, and fan.
6. Cara ngungkulan
| Masalah | Mungkin Cukang lantaranana | Solusi |
|---|---|---|
| Henteu aya kakuatan / Henteu hurung | Adaptor kakuatan teu nyambung leres; Masalah stop kontak. | Ensure power adapter is securely connected to the mini PC and a working power outlet. Try a different outlet. |
| Henteu aya tampilan dina monitor | HDMI cable loose or faulty; Incorrect input source on monitor. | Pariksa sambungan kabel HDMI. Pastikeun monitor disetel ka input HDMI anu leres. Cobi port atanapi kabel HDMI anu béda. |
| kinerja lalaunan | Too many applications running; Insufficient storage space; Outdated drivers. | Tutup aplikasi anu teu perlu. Ngosongkeun rohangan disk. Apdet Windows sareng supir. |
| Taya sambungan Wi-Fi | Wi-Fi adapter disabled; Router issue; Driver problem. | Check Wi-Fi settings in Windows. Restart your router. Update Wi-Fi drivers. |
| Taya audio | Incorrect audio output selected; Volume too low; Driver issue. | Check audio output settings in Windows. Increase volume. Update audio drivers. |
7. Spésifikasi
| Fitur | Rincian |
|---|---|
| Modél | Huidun H30 N150 mini computer |
| Prosesor | Intel Twin Lake N150 (up to 3.6GHz, 6W) |
| Ram | 16 GB DDR4 RAM |
| Panyimpenan | 512GB M.2 2280 SSD (Expandable up to 2TB 2.5" SATA HDD/SSD) |
| Grafika | Integrated Intel Graphics (up to 1000MHz), supports 4K dual display |
| Sistem operasi | Windows 11 Pro, Linux compatible |
| Konéktipitas Wireless | 5G WiFi (802.11a/b/g/n/ac), Bluetooth 4.2 |
| Palabuhan | 2x USB 3.0, 2x USB 2.0, 2x HDMI (4K@60Hz), 1x RJ45 LAN, 1x 3.5mm Audio Jack, 1x DC-in |
| Sistim cooling | Optimized solution with copper tube, aluminum heat sink, and 4,500 RPM fan |
| Diménsi | 9.37 x 7.28 x 2.48 inci |
| Beurat | 1.63 pon |
| Warna | Hideung |
8. Video Produk Resmi
Video: Hiji acara video produk resmicasing the Huidun Mini PC N150, highlighting its features and compact design.
9. Garansi jeung Rojongan
Huidun provides a 24-bulan jaminan kawates for the Mini PC H30 N150. Additionally, lifetime technical support is available for all microcomputers.
For any inquiries, technical assistance, or warranty claims, please contact our dedicated customer service team. You can find contact information on the Huidun official website or through your purchase platform. Our computer specialists are ready to provide professional and free services.
Image: Visual representation of Huidun's commitment to customer satisfaction, including 24-month warranty and lifetime technical support.
