DWVO Two-Tier Small Animal Cage with Wheels

Model: MADWV9yljR - Instruction Manual

Bubuka

Thank you for choosing the DWVO Two-Tier Small Animal Cage. This manual provides essential information for the safe and correct assembly, operation, and maintenance of your new pet habitat. Please read these instructions thoroughly before beginning assembly and retain them for future reference.

Émbaran Kasalametan

  • Always ensure all parts are securely fastened before placing your pet inside the cage.
  • Regularly inspect the cage for any damaged or loose components that could pose a hazard to your pet.
  • Keep small children and other pets away from the assembly area to prevent accidents.
  • This cage is designed for indoor use only.
  • Ensure the cage is placed on a stable, level surface.

Eusi pakét

Sateuacan dirakit, mangga pariksa heula sadaya komponénna aya sareng henteu ruksak. Upami aya bagian anu leungit atanapi ruksak, mangga ngahubungi layanan palanggan.

  • Cage panels (various sizes)
  • Platforms (2)
  • Ramps (2)
  • Slide-out tray (1)
  • Wheels (4, 2 with locks)
  • Assembly hardware (screws, nuts, connectors)
  • Buku pituduh

Setup sareng Majelis

Assembly is generally straightforward, though some users may find it requires careful attention to detail. Follow these steps for proper setup:

  1. Ngabongkar komponén: Carefully remove all parts from the packaging and lay them out on a clean, flat surface. Identify each component using the diagram below.
  2. Pasang Rangka Dasar: Connect the bottom cage panels to form the base structure. Ensure all connections are secure.
  3. Pasang Roda: Insert the four 360-degree rotatable wheels into the designated slots on the bottom of the cage frame. Two of the wheels include locking mechanisms for stability.
  4. Install Side and Back Panels: Attach the side and back wire panels to the base frame, ensuring they align correctly.
  5. Insert Slide-Out Tray: Slide the plastic waste tray into the designated slot at the bottom of the cage. This tray is designed for easy removal and cleaning.
  6. Install Platforms and Ramps: Position the two platforms at the desired heights within the cage. Attach the non-slip ramps to connect the levels. The ramps are wrapped in nylon for grip and paw protection.
  7. Attach Front Door Panel: Secure the front door panel, ensuring the unique door lock mechanism is correctly installed and functional. This lock is designed for enhanced security.
  8. Panel Luhur anu Aman: Attach the top panel of the cage. The top panel features an openable roof door for easy interaction and cleaning.
  9. Cék ahir: Double-check all connections, screws, and latches to ensure the cage is stable and secure for your pet.
Diagram showing the assembled DWVO Two-Tier Small Animal Cage with dimensions and key features labeled.

Gambar 1: Gemblengna view of the DWVO Two-Tier Small Animal Cage with dimensions and component breakdown. The cage measures approximately 32 inches (L) x 22 inches (W) x 33 inches (H). Key features like the slide-out tray, platforms, and wheels are indicated.

Parentah Operasi

This cage is designed for ease of use and pet comfort.

  • Accessing the Cage: The main front door provides primary access. Additionally, the top roof door can be opened for easier interaction with your pet or for cleaning.
  • Mékanisme Ngonci Aman: The door features a specially designed lock to prevent intelligent small animals from escaping. Ensure the lock is fully engaged after opening and closing the door.
  • Mobilitas: The cage is equipped with four 360-degree rotatable wheels, allowing for easy movement between indoor locations. Use the locking wheels to secure the cage in place when desired.
  • Multi-Level Environment: The two platforms and ramps nyadiakeun ample space for your pet to explore, play, and rest across different levels.
Close-up of the secure door lock mechanism on the DWVO small animal cage.

Figure 2: Detail of the secure door lock, designed to keep pets safely inside the cage.

Image showing one of the 360-degree rotatable wheels with an arrow indicating rotation.

Figure 3: A 360-degree rotatable wheel, highlighting the cage's easy mobility.

Pangropéa

Regular cleaning and maintenance will ensure a hygienic and safe environment for your pet.

  • beberesih poean: Remove the slide-out tray daily to dispose of waste and soiled bedding. Wipe the tray with a pet-safe cleaner and dry thoroughly before reinserting.
  • Beberesih Jero Mingguan: Once a week, remove your pet and all accessories from the cage. Disassemble platforms and ramps if necessary. Clean all cage surfaces, including wire mesh, platforms, and ramps, with a mild, pet-safe disinfectant. Rinse thoroughly and ensure all parts are completely dry before reassembling and returning your pet.
  • Ngabersihan Baki: The slide-out tray simplifies waste removal. Pull the tray out from the bottom of the cage, empty its contents, clean, and slide it back in.
A hand pulling out the black slide-out tray from the bottom of the cage, with arrows indicating the sliding motion.

Figure 4: The slide-out tray being removed for easy cleaning of animal waste.

Pamérésan masalah

Upami anjeun ngalaman masalah, tingali solusi umum ieu:

  • Kasesahan nalika assembly: Ensure you are following the steps in the correct order and that all panels are oriented as shown in the diagrams. Some connections may require firm pressure. If parts do not align, double-check for incorrect panel placement.
  • Ramps being removed by pet: Some intelligent pets may learn to dislodge the ramps. Ensure the ramps are securely hooked onto the platforms. Consider adding additional fasteners if your pet consistently removes them.
  • Pet chewing on ramp ngawengku: If your pet chews on the nylon ramp covers, monitor their behavior. If chewing becomes excessive or poses a choking hazard, remove the covers and consider alternative non-toxic ramp surfaces or chew toys to redirect their attention.
  • Cage instability: Verify that all screws and connectors are tightened. Ensure the cage is on a flat, even surface and that the locking wheels are engaged if the cage needs to remain stationary.

spésifikasi

Dimensi produk81.3 cm (L) x 55.9 cm (W) x 83.8 cm (H) (approx. 32"L x 22"W x 33"H)
Nomer Modél ItemMADWV9yljR
BahanPlastic (trays, platforms, ramps), Metal (cage wire)
WarnaHideung
Jumlah Tingkat2
Fitur hususEasy Assembly, Mobile (with wheels)
Mangpaat hususIndoor use for small animals (rodents, chinchillas, guinea pigs, hamsters, rabbits, hedgehogs)
Item Beurat12.1 kg (kira-kira 26.68 pon)

Garansi sareng Rojongan

For warranty information, missing parts, or technical support, please contact DWVO customer service through your retailer or the official DWVO website. Please have your model number (MADWV9yljR) and purchase date available when contacting support.
