Ingco CAGLI27153 Cordless Angle Grinder User Manual

1. Bubuka

Thank you for choosing the Ingco CAGLI27153 Cordless Angle Grinder. This manual provides essential information for the safe and effective operation, maintenance, and troubleshooting of your tool. Please read this manual thoroughly before use and keep it for future reference. This angle grinder features a powerful brushless motor, 20V battery compatibility, 1000W maximum input power, and variable speed settings for versatile applications.

Figure 1: Ingco CAGLI27153 Cordless Angle Grinder. This image displays the main unit of the angle grinder, highlighting its brushless motor, 1000W maximum power, and 115mm disc diameter. It also indicates that the battery and charger are sold separately.

2. Pitunjuk Kasalametan Umum

Salawasna turutan pancegahan kaamanan dasar pikeun ngirangan résiko seuneu, kejutan listrik, sareng tatu pribadi. Tetep manual ieu gunana pikeun rujukan gancang.

• Kasalametan Area Gawé: Tetep wewengkon gawé beresih jeung well-cahayana. Ulah ngajalankeun parabot kakuatan dina atmosfir ngabeledug, kayaning ku ayana cair kaduruk, gas, atawa lebu.
• Kasalametan listrik: Hindarkeun kontak awak sareng permukaan bumi atanapi grounded. Ulah ngalaan alat listrik ka hujan atawa kaayaan baseuh.
• Kasalametan Pribadi: Always wear eye protection (safety goggles) and hearing protection. Use a dust mask if operations create dust. Dress properly; avoid loose clothing or jewelry.
• Pamakéan sareng Perawatan Alat: Ulah maksakeun pakakas listrik. Anggo pakakas listrik anu pas pikeun aplikasi anjeun. Cabut batréna sateuacan ngadamel pangaluyuan, ngarobih asesoris, atanapi nyimpen pakakas listrik.
• Pamakéan sareng Perawatan Alat Batré: Ngecas ukur nganggo carjer anu ditunjuk ku produsén. Anggo alat-alat listrik ngan nganggo bungkus batré anu ditunjuk sacara khusus.

3. Specific Angle Grinder Safety Warnings

• Pakakas listrik ieu dimaksudkeun pikeun fungsina salaku panggiling atanapi alat motong. Baca sadaya peringatan kaamanan, pitunjuk, ilustrasi, sareng spésifikasi anu disayogikeun sareng alat listrik ieu.
• Anggo Alat Pelindung Diri (APD) anu pantes: Always wear safety glasses or goggles. Hearing protection, gloves, and a dust mask are also recommended.
• Ensure the guard is properly installed: The guard must be securely attached and positioned for maximum safety during operation.
• Paké asesoris bener: Only use grinding or cutting discs that are rated for the tool's speed and diameter (115mm) and have the correct M14 spindle thread.
• Cekel alatna pageuh: Always use the auxiliary handle and hold the tool with both hands to maintain control.
• Hindarkeun kickback: Be aware of the potential for kickback, especially when cutting. Maintain a firm grip and proper body positioning.
• Do not use for polishing or wire brushing: This tool is designed for grinding and cutting only.

4. Pedaran Produk sareng Komponen

Familiarize yourself with the parts of your Ingco CAGLI27153 angle grinder.

Figure 2: Ingco CAGLI27153 Cordless Angle Grinder. This image provides a clear view of the angle grinder's main body, including the motor housing, gear head, and battery interface.

• Tombol Konci Spindle: Dianggo pikeun ngunci spindle pikeun ngaganti cakram.
• Gear Head: Houses the gears and spindle.
• Pelindung Cakram: Ngajaga tina percikan api sareng lebu.
• Gagang bantu: Nyadiakeun cengkraman sareng kontrol tambahan.
• Saklar on/off: Aktipkeun sareng mareuman alat.
• Pencét Kontrol Kecepatan: Adjusts the no-load speed (3000/6000/9000rpm).
• Antarmuka batré: Where the 20V battery pack is inserted.
• Motor Brushless: Nyadiakeun kakuatan efisien sareng umur alat anu langkung panjang.

Figure 3: Ingco CAGLI27153 Cordless Angle Grinder with Auxiliary Handle. This view emphasizes the ergonomic design and the attachment point for the auxiliary handle, crucial for two-handed operation.

5. Setélan

Sateuacan ngoperasikeun panggiling sudut, pastikeun parantos dipasang kalayan leres.

5.1 Ngagantelkeun gagang bantu

1. The auxiliary handle can be screwed into either side of the gear head, depending on user preference and application.
2. Thread the handle clockwise until it is securely tightened.

5.2 Installing/Removing the Grinding Disc

Catetan: Grinding discs are not included and must be purchased separately. Ensure the disc diameter is 115mm and has an M14 spindle thread.

1. Pastikeun pak batré dipiceun tina alat.
2. Pencét jeung tahan tombol konci spindle.
3. Ngagunakeun rengkuh disadiakeun, loosen jeung cabut nut flange luar ku cara ngarobahna counter-jarum jam.
4. Place the grinding disc onto the inner flange, ensuring it sits flush.
5. Ganti nut flange luar jeung tighten eta jarum jam jeung rengkuh bari nahan tombol konci spindle. Ulah overighten.
6. Pikeun ngahapus, balikkeun léngkah ieu.

5.3 Masang/Cabut Batré Pack

Catetan: Batré sareng carjer dijual misah.

1. To install, align the battery pack with the battery interface on the tool and slide it in until it clicks securely into place.
2. Pikeun nyabut, pencét tombol ngaleupaskeun batré sareng geser pak batré kaluar.

6. Parentah Operasi

Turutan léngkah ieu pikeun operasi anu aman sareng efektif.

6.1 Powering on / Pareum

1. Ensure a fully charged battery is installed and the disc is correctly mounted.
2. To start the tool, slide the On/Off switch forward.
3. To stop the tool, slide the On/Off switch backward.

6.2 Nyaluyukeun Speed

The tool features a variable speed control dial with settings for 3000, 6000, and 9000 RPM (revolutions per minute). Adjust the speed according to the material and application:

• Lower Speeds (e.g., 3000 RPM): Suitable for softer materials or applications requiring more control.
• Higher Speeds (e.g., 9000 RPM): Ideal for harder materials and faster material removal.

6.3 Téhnik grind jeung motong

• Ngagiling: Hold the tool at a 15-30 degree angle to the workpiece. Apply moderate pressure and move the tool smoothly across the surface.
• motong: Hold the tool perpendicular (90 degrees) to the workpiece. Allow the disc to do the work; do not force it. Ensure the workpiece is securely clamped.
• Always allow the tool to reach full speed before contacting the workpiece.
• Avoid overloading the tool, which can lead to overheating and damage.

7. Pangropéa

Pangropéa rutin ngajamin kinerja optimal sareng manjangkeun umur alat anjeun.

• beberesih: Sanggeus unggal dipaké, bersihkeun alat ku lemes, damp lawon. Ulah make bahan kimia kasar atawa cleaners abrasive. Jaga bukaan ventilasi bersih tina lebu sareng lebu.
• Inspeksi disk: Pariksa sacara rutin cakram panggilingan sareng motong pikeun ayana karusakan, retakan, atanapi karusakan. Ganti cakram anu ruksak langsung.
• Inspeksi penjaga: Ensure the disc guard is securely attached and undamaged.
• Perawatan batré: Simpen bungkus batré di tempat anu tiis sareng garing jauh tina sinar panonpoé langsung. Ulah nyimpen batré pinuh discharged pikeun période nambahan.
• Motor Brushless: The brushless motor requires less maintenance compared to brushed motors, as there are no carbon brushes to replace.
• Panyimpenan: Simpen alat sareng asesorisna di tempat anu garing, aman, sareng teu kahontal ku barudak.

8. Cara ngungkulan

If you encounter issues with your angle grinder, refer to the following common problems and solutions.

9. Spésifikasi

Technical data for the Ingco CAGLI27153 Cordless Angle Grinder.

• model: CAGLI27153
• Tipe Motor: Brushless
• Voltage: 20V
• Daya Input Maksimum: 1000W
• Laju tanpa beban: 3000/6000/9000 rpm (variable)
• Diaméter piringan: 115 mm (4-1/2")
• Spindle Thread: M14
• Beurat (Alat Ngan): Kira-kira 1.85 kg
• ukuran: Kira-kira 32.5 x 12.5 x 10.5 cm
• Komponén Kaasup: Auxiliary Handle (Battery and charger sold separately)

10. Garansi jeung Rojongan

Ingco products are manufactured to high-quality standards. For information regarding warranty terms and conditions, please refer to the warranty card included with your purchase or contact your local Ingco dealer or customer support. Keep your proof of purchase for any warranty claims.
