PECSU G4S Android 14 MP3 Player User Manual

1. Bubuka

The PECSU G4S MP3 Player is a versatile portable music and media device running on the Android 14 operating system. It features a 4-inch touch screen, extensive storage, and connectivity options, designed for a rich multimedia experience with robust parental controls.

Figure 1: PECSU G4S MP3 Player with Android 14 interface.

2. Eusi Paket

Ensure all items listed below are present in your product box:

• MP3 Player (PECSU G4S) x 1
• 64GB Micro SD Card x 1 (pre-installed or separate)
• Silicone Case x 1
• Kabel Data USB-C x 1
• Wired Headphones x 1
• Buku Panduan x 1

3. Setup Awal

3.1. Powering on / Pareum

• Pikeun Ngahurungkeun: Press and hold the Power button (located on the side) until the PECSU logo appears on the screen.
• Pikeun mareuman: Press and hold the Power button until the power-off options appear. Select 'Power Off'.
• Pikeun ngamimitian deui: Press and hold the Power button until the power-off options appear. Select 'Restart'.

3.2. Nyelapkeun Kartu MicroSD

The device comes with a 64GB Micro SD card. If not pre-installed, locate the Micro SD card slot on the side of the device. Gently insert the card with the gold contacts facing down until it clicks into place. The device supports expansion up to 1TB.

Figure 2: Inserting the MicroSD card.

3.3. Ngecas Alat

Connect the USB-C data cable to the charging port at the bottom of the device and the other end to a USB power adapter (not included) or a computer. The battery indicator on the screen will show charging status. A full charge provides extended playback time.

Figure 3: USB-C charging port and 3.5mm headphone jack.

4. Ngoperasikeun Alat Anjeun

4.1. Napigasi Interface

The PECSU G4S features a responsive 4-inch IPS touch screen. Swipe left or right to navigate between app pages. Tap on an app icon to open it. Use the navigation buttons at the bottom of the screen (Back, Home, Recent Apps) for easy control.

4.2. Puterkeun Musik

The device supports various audio formats including MP3, WMA, AAC, WAV, APE, FLAC, and OGG. You can use pre-installed music apps like Spotify, Amazon Music, or the default music player. The device also supports equalizer settings, various playback modes (loop, shuffle, sequential), and variable speed playback.

Figure 4: Music playback interface with equalizer and mode options.

Mindahkeun Musik Files

Pikeun nransper musik files from your computer to the PECSU G4S, connect the device using the provided USB-C cable. The device will appear as a removable storage drive on your computer. You can then drag and drop your music files into the 'Music' folder or a custom folder on the device's internal storage or SD card.

4.3. Puteran pidéo

The device supports video playback for formats such as RM, AVI, RMVB, FLV, MP4, MKV, MPG, and MOV. Use a compatible video player app to enjoy your videos on the 4-inch screen.

4.4. Wi-Fi jeung Bluetooth Konéktipitas

The PECSU G4S supports dual-band Wi-Fi (5GHz & 2.4GHz) for stable internet connection and Bluetooth 5.0 for wireless audio. To connect to Wi-Fi or pair Bluetooth devices, go to Setelan > Jaringan & internét or Setelan > Alat nu disambungkeun.

Figure 5: Bluetooth 5.0 connectivity options.

4.5. Kadali kolot

Utilize the unique 'Parental Management' function to control app access. This feature allows you to enable or disable specific applications, including the Google Play Store, using a parent password. This ensures a safe and controlled environment for younger users.

Figure 6: Parental Management interface.

4.6. Eye-Care Mode

The 4-inch IPS touch screen supports an eye-care mode and night-light function to reduce eye strain during prolonged use. Activate this mode through the device settings for a more comfortable viewpangalaman.

Figure 7: Eye-Care Mode features.

4.7. Voice Recording & FM Radio

The device includes a pre-installed voice recording function for capturing audio. For FM Radio, you can use the pre-installed 'FM Radio' app (requires wired headphones as an antenna) or download apps like iHeartRadio and TuneIn Radio from the Google Play Store.

5. Pangropéa

To ensure the longevity and optimal performance of your PECSU G4S MP3 Player, follow these maintenance guidelines:

• beberesih: Use a soft, dry, lint-free cloth to clean the screen and body of the device. Avoid using harsh chemicals or abrasive materials.
• Panyimpenan: Simpen alat ieu di tempat anu tiis sareng garing, jauh tina sinar panonpoé langsung, suhu anu ekstrim, sareng kalembaban.
• Perawatan batré: Avoid fully discharging the battery frequently. For long-term storage, charge the device to about 50% and power it off.
• Perlindungan: Use the included silicone case to protect the device from scratches and minor impacts.

6. Cara ngungkulan

If you encounter any issues with your PECSU G4S MP3 Player, refer to the following common troubleshooting steps:

• Alat Teu Ngabales: If the device freezes or becomes unresponsive, perform a soft reset by pressing and holding the Power button for approximately 10 seconds until the device restarts.
• Cannot Connect to Wi-Fi/Bluetooth: Ensure Wi-Fi or Bluetooth is enabled in Settings. Try restarting the device and your router/Bluetooth accessory.
• Music/Videos Not Playing: Pariksa yén média files are in a supported format and are stored in the correct folders. Ensure the volume is not muted or too low.
• Batré gancang nyusut: Reduce screen brightness, close unused apps, and disable Wi-Fi/Bluetooth when not in use. Check for any background apps consuming excessive power.
• Apps Not Working: Ensure apps are updated to their latest versions. Clear the app's cache or data in Settings > Apps. If an app is disabled via Parental Management, re-enable it.
• Pabrik Reset: As a last resort, if persistent issues occur, you can perform a factory reset via Setélan> Sistem> Pilihan Reset> Pupus sadaya data (reset pabrik). Note: This will erase all data on the device. Back up important files sateuacan neraskeun.

7. Spésifikasi

8. Garansi jeung Rojongan

The PECSU G4S MP3 Player comes with a manufacturer's warranty. For any unexpected issues, warranty-related inquiries, or technical support, please contact the PECSU support team. They are available 24/7 to assist you.

For further assistance, please refer to the contact information provided in your product packaging or visit the official PECSU websitus.
