1. Produk Langkungview
The VEVOR NTG-SA15B Pressure Washer Hose Reel is designed for efficient and tangle-free storage of your pressure washer hose. Featuring an auto-rewinding mechanism and a durable steel construction, it supports up to 4000 PSI and is suitable for various cleaning tasks. Its flexible mounting options allow for wall, ceiling, or floor installation.
Fitur konci:
- Auto Rewind: High-tension retraction spring for stable, automatic hose rewind, reducing manual effort and tangles.
- adjustment fléksibel: Adjustable guide arm allows precise hose locking at various lengths without continuous pulling, preventing tangling and extending hose life.
- 360-Degree Swivel Inlet: Solid brass, leakproof, and corrosion-resistant swivel joint for easy connection and high-pressure flow.
- Kasaluyuan: Designed for 3/8-inch hoses up to 50 feet (M22 connector), supporting up to 4000 PSI and 212°F.
- Pamasangan serbaguna: Mountable on wall, ceiling, or floor, ideal for garages, car repair, gardening, and workshops.
Figure 1: VEVOR NTG-SA15B Pressure Washer Hose Reel.
2. Parentah Kasalametan
Always observe basic safety precautions when using this product to reduce the risk of injury or damage.
- Baca sareng pahami sadaya pitunjuk sateuacan dipasang sareng dioperasikeun.
- Wear appropriate personal protective equipment (PPE), such as safety glasses, during installation and use.
- Ensure the mounting surface is strong enough to support the weight of the hose reel and the hose, especially when fully extended and under pressure.
- Do not exceed the maximum pressure rating of 4000 PSI or the maximum temperature of 212°F (100°C).
- When pre-tensioning the spring, exercise extreme caution. The spring's recoil force is strong and can cause injury if not handled properly. Ensure the reel is securely locked before releasing cekelan anjeun.
- Always ensure all connections are tight and leak-free before operating the pressure washer.
- Jauhkeun barudak jeung piaraan ti wewengkon gawé.
- Do not attempt to repair or modify the hose reel if you are not qualified. Contact customer support for assistance.
3. Setup & Instalasi
This section provides instructions for setting up and installing your VEVOR Pressure Washer Hose Reel. The reel can be mounted on a wall, ceiling, or floor.
3.1 Pilihan pamasangan
Figure 2: The hose reel can be flexibly installed on the floor, wall, or ceiling to suit various environments.
Choose a suitable location for mounting the hose reel, ensuring it is on a stable and structurally sound surface capable of supporting the unit's weight and the forces exerted during hose retraction.
3.2 Pre-tensioning the Spring
- Rotate the reel in the direction indicated by the arrow on the sticker to pre-tension the spring.
- Gradually pre-tension the spring by turning the reel about 20 circles.
- Be cautious during this process as the spring's recoil force is strong and can cause injury.
- Lock the reel in place with the pawl. Listen for a "click" sound to confirm it's locked. If the reel doesn't lock and turns back due to spring tension, it could damage the spring.
Video 1: Demonstrates the process of pre-tensioning the spring, inserting the high-pressure hose, installing the hose stopper, and connecting the inlet tube.
3.3 Pamasangan selang
- Insert the 50 ft, 3/8-inch high-pressure hose into the reel's outlet.
- Hold the high-pressure hose firmly, release the pawl, and allow the reel to rotate slowly, retracting the hose.
- Install the hose stopper at the desired position on the hose to prevent it from fully retracting into the reel. Use the provided tools to secure the stopper.
Figure 3: Illustration of the hose stopper being installed on the high-pressure hose.
3.4 Inlet Tube Connection
Connect the inlet tube to the 360-degree swivel inlet on the hose reel. Ensure a secure and leak-free connection. This inlet connects the hose reel to your pressure washer.
angka 4: Tutup-up view of the 360-degree solid brass swivel inlet, designed for leak-resistant and corrosion-resistant connections.
4. Operasi
Operating your VEVOR Pressure Washer Hose Reel is straightforward. Follow these steps for safe and effective use.
- Extend the Hose: Pull the high-pressure hose out to the desired length. The adjustable guide arm allows you to lock the hose at various lengths without continuous pulling.
- Mékanisme ngonci: To lock the hose at a specific length, pull the hose out slightly further until you hear a click, then slowly release it. The hose will remain extended.
- Retracting the Hose: To retract the hose, pull it out slightly again to disengage the locking mechanism. Then, slowly guide the hose back into the reel, allowing the auto-rewind feature to coil it neatly. Always maintain a light grip on the hose during retraction to prevent rapid recoil and potential injury or damage.
- Nyambungkeun ka Mesin Cuci Tekanan: Connect the inlet tube of the hose reel to your pressure washer's high-pressure outlet. Ensure all connections are secure before turning on the pressure washer.
- Ngagunakeun Pressure Washer: Operate your pressure washer according to its own instruction manual.
Figure 5: A user demonstrating the use of the VEVOR Pressure Washer Hose Reel for car washing, highlighting its tangle-free storage.
5. Pangropéa
Regular maintenance ensures the longevity and optimal performance of your VEVOR Pressure Washer Hose Reel.
- beberesih: Periodically clean the exterior of the hose reel with a damp lawon. Hindarkeun pamakéan bahan kimia kasar nu bisa ngaruksak finish.
- Inspeksi selang: Regularly inspect the high-pressure hose for any signs of wear, cuts, kinks, or leaks. Replace damaged hoses immediately to prevent accidents.
- Cék sambungan: Before each use, check all connections (inlet, outlet, and pressure washer connections) for tightness. Tighten any loose connections to prevent leaks.
- Mékanisme Pegas: If the auto-rewind mechanism becomes sluggish, it may require re-tensioning or professional servicing. Refer to the setup section for re-tensioning instructions, but exercise caution.
- Panyimpenan: When not in use, especially during cold weather, drain any remaining water from the hose and store the reel in a dry, protected area to prevent freezing and damage.
6. Cara ngungkulan
This section addresses common issues you might encounter with your VEVOR Pressure Washer Hose Reel.
| Masalah | Mungkin Cukang lantaranana | Solusi |
|---|---|---|
| Hose does not retract fully or is sluggish. | Spring tension is too low. | Re-tension the spring as described in the "Setup & Installation" section (Section 3.2). |
| Hose does not lock when extended. | Locking mechanism (pawl) is obstructed or damaged. | Check for debris obstructing the pawl. If damaged, contact customer support. |
| Cai bocor tina sambungan. | Loose connections or worn O-rings/seals. | Tighten all connections. Inspect and replace any damaged O-rings or seals. Ensure proper use of thread sealant if applicable. |
| Hose is tangled or kinked. | Improper retraction or obstruction. | Ensure the hose is guided smoothly during retraction. Check the adjustable guide arm for proper function. |
| Hose stopper slides out of position. | Stopper not securely fastened. | Re-tighten the hose stopper using the provided tools. |
7. Spésifikasi
Detailed technical specifications for the VEVOR NTG-SA15B Pressure Washer Hose Reel.
| Fitur | Rincian |
|---|---|
| Nomer modél | NTG-SA15B |
| merek | VEVOR |
| Bahan | Steel, Brass |
| Compatible Hose Size | 3/8 inci |
| Maximum Hose Capacity | 50 ft / 15.2 m |
| Working Pressure (Max) | 4000 PSI |
| Suhu Cai Max | 212°F / 100°C |
| Selang Inlet | 3/8-inch Diameter, 50 in / 1.3 m Length |
| Ukuran barang (L x W x H) | 15.75 x 8.07 x 16.34 inci (400 x 205 x 415 mm) |
| Item Beurat | 24.91 pon / 11.3 kg |
| Tipe Pamasangan | Wall Mount (also suitable for floor/ceiling) |
| Modeu Operasi | Automatic (Retractable) |
| UPC | 197988886600 |
Asesoris kaasup:
- 1 x M22 (14 mm Male) to M22 Male Thread Adapter
- 1 x 3/8-inch to M22 (14 mm) Zinc-Plated Steel Quick Connector
- 1 x Tape (3.5 m)
- 4 x Sekrup Ékspansi
- 1 x Hose Stop Block
- 2 x Internal Hex Screw Assemblies
- 5 x External Hex Bolts
- 5 x Kacang Hex
- 5 x Datar Washers
- 1 x Manual Pamaké
Figure 6: Diagram showing key dimensions and a list of included accessories for the VEVOR NTG-SA15B hose reel.
8. Jaminan & Dukungan
VEVOR products are designed and built to high-quality standards. This product is covered by a limited warranty from the date of purchase. For specific warranty terms and conditions, please refer to the warranty card included with your product or visit the official VEVOR websitus.
Pikeun rojongan teknis, bantuan ngungkulan, atawa nanya ngeunaan suku cadang ngagantian, mangga ngahubungan layanan palanggan VEVOR ngaliwatan resmi maranéhanana. website or the contact information provided in your product packaging. When contacting support, please have your model number (NTG-SA15B) and purchase date available.
