Azmsary Slushie and Ice Cream Machine (Model ASDA1) User Manual

1. Bubuka

Thank you for choosing the Azmsary Slushie and Ice Cream Machine. This appliance is designed to create a variety of frozen beverages and desserts, including slushies, ice cream, frappes, milkshakes, and frozen juices, with ease and efficiency. This manual provides essential information for safe operation, setup, usage, maintenance, and troubleshooting to ensure optimal performance and longevity of your machine.

Image 1: Azmsary Slushie and Ice Cream Machine, showcasing its sleek design and various frozen treats it can produce.

2. Parentah Kasalametan penting

Mangga baca sagala parentah taliti saméméh ngagunakeun alat pikeun nyegah tatu atawa karuksakan. Simpen manual ieu pikeun rujukan ka hareup.

• Always ensure the machine is placed on a stable, level surface away from heat sources and direct sunlight.
• Ulah neuleumkeun unit utama, ari, atawa nyolok kana cai atawa cairan séjén.
• Unplug the machine from the outlet when not in use, before assembling or disassembling parts, and before cleaning.
• Keep hands and utensils out of the container during operation to prevent injury and damage to the machine.
• Ulah ngoperasikeun mesin nganggo kabel atanapi colokan anu rusak, atanapi saatos alat henteu berfungsi atanapi ruksak ku cara naon waé.
• Alat ieu henteu dimaksudkeun pikeun dianggo ku jalma anu kakurangan kamampuan fisik, indrawi, atanapi mental, atanapi kirang pangalaman sareng pangaweruh, kecuali aranjeunna dipasihan pangawasan atanapi petunjuk ngeunaan panggunaan alat ku jalma anu tanggung jawab kana kasalametanana.
• Barudak kedah diawaskeun pikeun mastikeun yén aranjeunna henteu maén sareng alatna.
• Paké ngan kantétan jeung asesoris dianjurkeun ku produsén.
• Ensure the lid is securely in place before operating the machine.
• Do not overfill the container. Refer to the MAX FILL line.
• Using unsuitable ingredients (e.g., too low sugar content or too high alcohol content) may cause damage to the machine. Refer to the sugar and alcohol content guidelines in the operating section.

3. Produk Langkungview

Familiarize yourself with the main components of your Azmsary Slushie and Ice Cream Machine:

• Unit Utama: Houses the refrigeration system and control panel.
• Wadah transparan: Where ingredients are mixed and frozen. Features MAX FILL and MIN FILL indicators.
• Campur Dayung: Continuously stirs the ingredients to achieve the desired consistency.
• Dispensing spout: For serving your frozen treats.
• Baki netes: Collects any drips or spills for easy cleanup.
• Panel kontrol sareng tampilan LED: Allows selection of programs, displays temperature, and provides status indicators.
• tutup: Covers the transparent container during operation. Includes an opening for adding liquids.

Image 2: Close-up of the control panel, showing the LED display and various program selection buttons.

4. Setélan

1. Ngabongkar bungkusan: Cabut sadaya komponén tina bungkusna kalayan ati-ati. Simpen bahan bungkus kanggo panyimpenan atanapi transportasi ka hareup.
2. Bersihan awal: Before first use, clean all removable parts (transparent container, mixing paddle, lid, dispensing spout, drip tray) with warm, soapy water. Rinse thoroughly and dry completely. Wipe the main unit with a damp lawon.
3. Majelis:
   • Place the main unit on a clean, dry, and stable surface.
   • Insert the mixing paddle into the transparent container.
   • Attach the transparent container to the main unit, ensuring it is securely locked in place.
   • Teundeun tutup dina luhureun wadahna.
   • Position the drip tray at the base of the dispensing spout.
4. Sambungan Daya: Plug the power cord into a grounded electrical outlet. The LED display will illuminate.

Image 3: Visual guide illustrating the simple 3-step process for using the machine: Add liquids, select a mode, and wait for the frozen treat.

5. Parentah Operasi

The Azmsary machine features 6 preset programs for various frozen treats. Follow these steps for operation:

1. Nyiapkeun Bahan: Ensure your liquid ingredients are pre-chilled for best results, though pre-chilling is not strictly required due to the machine's quick-freezing technology.
2. Tambahkeun Bahan: Pour your mixed liquid into the transparent container through the lid opening. Do not exceed the MAX FILL line (85oz for slush, 64oz for liquid) and ensure it is above the MIN FILL line (16oz).
3. Pilih Program: On the LED display, choose one of the 6 preset programs by pressing the corresponding button:
   • És krim: For creamy soft-serve ice cream.
   • Slush: For classic slushie consistency.
   • Frappe: Optimized for coffee-based or similar blended drinks.
   • Slush Spike: For alcoholic frozen beverages.
   • Susu kocok: For thick and smooth milkshakes.
   • Jus beku: Pikeun nyegerkeun jus buah beku.
4. Mimitian Operasi: Press the Start/Pause button. The machine will begin the freezing and mixing process. The preparation time typically ranges from 15 to 45 minutes, depending on the selected program, ingredients, and initial temperature.
5. Dispense: Once the program is complete and the desired consistency is reached, place a cup under the dispensing spout and pull the lever to serve.
6. Night Mode (Keep Cool Function): If you wish to keep your frozen treat chilled for an extended period (up to 12 hours) after preparation, activate the Night Mode. This function maintains a stable temperature (3-4°C) while reducing energy consumption.

Sugar and Alcohol Content Guidelines:

To ensure proper freezing and prevent damage to the machine, adhere to the following guidelines:

• Kandungan Gula: For slushies, the sugar content should be above 4%. Sugar-free substitutes or artificial sweeteners may not allow for proper freezing.
• Kandungan Alkohol: For alcoholic beverages, the alcohol percentage should be below 16%. High alcohol content can prevent freezing.

Image 4: Chart detailing recommended sugar and alcohol percentages for optimal machine performance and drink consistency.

6. Pangropéa jeung beberesih

Regular cleaning ensures hygiene and extends the life of your machine. The Azmsary machine offers convenient cleaning options:

1. Automatic Cleaning (Rinse Mode):
   • After dispensing, pour clean water into the container up to the MIN FILL line.
   • Select the "Rinse" mode on the control panel. The machine will automatically stir and clean the interior.
   • Once complete, drain the water through the dispensing spout. Repeat if necessary.
2. Beberesih manual:
   • Cabut colokan mesin.
   • Disassemble all removable parts: transparent container, mixing paddle, lid, dispensing spout, and drip tray.
   • Wash these parts with warm, soapy water. The removable parts are dishwasher-safe for added convenience.
   • Bilas tuntas sareng antepkeun sadaya bagian garing sadayana sateuacan dipasang deui atanapi disimpen.
   • Ngusap bagian luar unit utama nganggo iklanamp lawon. Ulah make cleaners abrasive atawa scourers.

Image 5: Illustration of the three cleaning options: automatic rinse mode, dishwasher-safe removable parts, and effortless manual cleaning.

7. Cara ngungkulan

Upami anjeun mendakan masalah sareng mesin anjeun, tingal masalah sareng solusi umum ieu:

If the problem persists after attempting these solutions, please contact Azmsary customer support.

8. Spésifikasi

• merek: Azmsary
• Ngaran modél: FS306-AS
• Jumlah modél: ASDA1
• warna: Hideung
• Kapasitas: 85oz (Slush), 64oz (Liquid)
• Bahan: Beusi sténless
• Beurat barang: 29.5 pon (13.4 Kilogram)
• Ukuran produk: 11.02 x 20.08 x 21.26 inci
• Modeu operasi: Otomatis
• Fitur husus: Automatic Clean, Digital Display, Keep Cool Function, Low Noise, Touchpad Control
• Komponén Kaasup: Ice cream machine, Slushie machine

9. Garansi jeung Rojongan

Azmsary is committed to providing high-quality products and customer satisfaction. Your Azmsary Slushie and Ice Cream Machine comes with the following:

• Garansi 1 Taun: Ngawengku cacad manufaktur sareng gangguan fungsi dina panggunaan normal.
• Jaminan Duit Balik 30 Dinten: For returns within 30 days of purchase.
• Rojongan Téknis Hirupna: Access to technical assistance for the lifespan of your product.

For warranty claims, technical assistance, or any product-related inquiries, please contact Azmsary customer service through the official websitus atanapi platform pameseran Anjeun.
